Gigabyte B760 GAMING X AX Motherboard - Supports Intel Core 14th Gen CPUs, 8+1+1 Phases Digital VRM, up to 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2 cijene

Technical details
Warranty period: 3 year(s)

Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel Core i3, Intel Core i5, Intel Celeron, Intel Core i7, Intel Core i9, Intel Pentium Gold
Maximum internal memory supported by processor: 192 GB
Processor socket: LGA 1700
Processor manufacturer: Intel

Graphics
Parallel processing technology support: Not supported
HDCP: Yes
DirectX version: 12.0
Maximum resolution: 4096 x 2304 pixels

Features
PC health monitoring: Fan, Temperature, Voltage, Water cooling
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset: Intel B760 Express
Product colour: Bronze
Motherboard chipset family: Intel

Memory
Supported memory module capacities: 48GB, 32GB, 12GB, 8GB, 16GB, 1GB, 2GB, 4GB
Unbuffered memory: Yes
Supported memory clock speeds: 6000, 6200, 7000, 6800, 5200, 4000, 4800, 6600, 6400 MHz, 7600, 7400, 5600, 7200 MHz, 5800, 5400
Maximum internal memory: 192 GB
Supported memory clock speed (max): 7600 MHz
Memory slots type: DIMM
Number of memory slots: 4
Memory channels: Dualchannel
Supported memory types: DDR5SDRAM

Weight & dimensions
Depth: 244 mm
Width: 305 mm
Height: 35 mm

Network
Bluetooth: Yes
WLAN controller model: Intel WiFi 6E AX211
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
WiFi standards: WiFi 6E (802.11ax), 802.11a, WiFi 6 (802.11ax), WiFi 5 (802.11ac), 802.11g, WiFi 4 (802.11n), 802.11b
WiFi: Yes
Bluetooth version: 5.2
Top WiFi standard: WiFi 6E (802.11ax)

Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 4
EPS power connector (8pin): Yes
Front panel connector: Yes
S/PDIF out connector: Yes
CPU fan connector: Yes
USB 2.0 connectors: 2
Front panel audio connector: Yes
Serial port headers: 1
ATX Power connector (24pin): Yes
Total number of SATA connectors: 4
12V power connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
TPM connector: Yes

BIOS
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes

Packaging data
Package weight: 1.66 kg
Package depth: 270 mm
Package width: 335 mm
Package height: 80 mm
Bundled software: Norton Internet Security

Packaging content
Batteries included: Yes
Cables included: SATA

Storage controllers
RAID levels: 5, 0, 1, 10
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 7
Number of HDDs supported: 4

Rear panel I/O ports
USB 2.0 ports quantity: 5
DisplayPorts quantity: 1
USB connector type: USB TypeA, USB TypeC
Ethernet LAN (RJ45) ports: 1
DisplayPort version: 1.2
USB 3.2 Gen 1 (3.1 Gen 1) TypeC ports quantity: 1
WiFiAP antenna jack: 2
Microphone in: Yes
HDMI version: 2.0
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 1
Headphone outputs: 6
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 1

Expansion slots
PCI Express x16 slots: 3
Number of M.2 (M) slots: 3

Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery weight: 3 g
Battery technology: LithiumManganese Dioxide (LiMnO2)
Number of battery cells: 1

Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
