Opis i karakteristike
Design
LED indicators: Power
Wall mountable: Yes
International Protection (IP) code: IP30
DIN rail mounting: Yes
Housing material: Metal
Product colour: Blue
Power
Power consumption (max): 2.8 W
DC input voltage: 9 48 V
Input voltage: 9 48 V
Input current: 24 A
Operational conditions
Operating relative humidity (HH): 5 90%
Operating temperature (TT): 40 75 C
Heat dissipation: 9.5 BTU/h
Storage relative humidity (HH): 5 90%
Storage temperature (TT): 40 75 C
Management features
Switch type: Unmanaged
Weight & dimensions
Weight: 252 g
Width: 30 mm
Height: 104 mm
Depth: 70 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3az, IEEE 802.3, IEEE 802.1p
Autonegotiation: Yes
Cable types supported: Cat5, Cat5e, Cat4, Cat3, Cat6
Full duplex: Yes
Auto MDI/MDIX: Yes
10G support: No
Ethernet LAN data rates: 10,100,1000 Mbit/s
Flow control support: Yes
Half duplex: Yes
Performance
Maximum data transfer rate: 1000 Mbit/s
Ports & interfaces
Basic switching RJ45 Ethernet ports quantity: 4
Fiber ports quantity: 1
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fiber optic connector: SFP
SFP module slots quantity: 1
Other features
Ethernet interface type: Gigabit Ethernet
Connectivity technology: Wired
Ethernet LAN (RJ45) ports: 4
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames support: Yes
Jumbo frames: 9000
Storeandforward: Yes
MAC address table: 4000 entries
Throughput: 7.4 Mpps
Switching capacity: 10 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
