Opis i karakteristike
Design
Wall mountable: Yes
International Protection (IP) code: IP30
LED indicators: Link, Power, Activity
Stackable: No
DIN rail mounting: Yes
Rack mounting: No
Housing material: Metal
Product colour: Blue
Power
DC input voltage: 24 V
Power protection features: Reverse polarity
Power consumption (typical): 8.7 W
Redundant power supply (RPS) support: Yes
Input voltage: 12 48 V
Operational conditions
Operating relative humidity (HH): 5 95%
Heat dissipation: 29.69 BTU/h
Operating temperature (TT): 40 75 C
Storage relative humidity (HH): 5 95%
Storage temperature (TT): 40 75 C
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 135 mm
Weight: 540 g
Width: 56 mm
Depth: 87 mm
Network
10G support: No
Flow control support: Yes
Networking standards: IEEE 802.3x, IEEE 802.3z, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u
Copper ethernet cabling technology: 100BASETX, 10BASET, 1000BASET
Autonegotiation: Yes
Full duplex: Yes
Auto MDI/MDIX: Yes
Cable types supported: Cat5, Cat5e, Cat6
Ports & interfaces
Fiber optic connector: SFP
SFP module slots quantity: 2
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 8
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 20 Gbit/s
Jumbo frames: 9216
Jumbo frames support: Yes
Throughput: 14.88 Mpps
MAC address table: 4000 entries
Storeandforward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Optical fiber
Fiber ethernet cabling technology: 100BASEFX
Transmission distance (max): 60 km
