Opis i karakteristike
Design
Form factor: 1U
LED indicators: Power, PoE, Activity, Link, System
Product colour: Grey
Market segment: Business
Rack mounting: Yes
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 240 V
Power consumption (max): 440 W
Redundant power supply (RPS) support: Yes
Power source: AC
Number of power supply units: 2
Power supply included: Yes
Security
Security algorithms: SNMPv2, HTTPS, SNMPv2c, SNMPv3, SNMP
Authentication: MACbased authentication
DHCP features: DHCP client, DHCP snooping
Access Control List (ACL): Yes
IGMP snooping: Yes
Authentication type: RADIUS
Operational conditions
Operating relative humidity (HH): 10 90%
Operating temperature (TT): 5 50 C
Storage temperature (TT): 10 70 C
Storage relative humidity (HH): 5 95%
Heat dissipation: 136.48 BTU/h
Management features
Webbased management: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Switch layer: L2/L3
Configuring Location Settings (CLI): Yes
ARP inspection: Yes
Weight & dimensions
Weight: 4.8 kg
Depth: 350 mm
Height: 44 mm
Width: 440 mm
Network
QinQ implementation: QinQ
Networking standards: IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z, IEEE 802.3u, IEEE 802.3af, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s
Copper ethernet cabling technology: 1000BASEX, 100BASETX, 1000BASET, 10BASET
VLAN support: Yes
10G support: Yes
Number of VLANs: 4000
Flow control support: Yes
Virtual LAN features: MAC addressbased VLAN, Protocolbased VLAN, IP subnetbased VLAN
Link aggregation: Yes
Spanning tree protocol: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Performance
Noise level: 45 dB
Internal memory: 256 MB
Memory type: Flash
Flash memory: 512 MB
Mean time between failures (MTBF): 100000 h
Fanless: No
Telnet: Yes
Packaging content
Quick start guide: Yes
Cables included: Power
Rack mount kit: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
IPv4 & IPv6 features: Dual stack IPv4/IPv6
Ports & interfaces
Power connector: ACin jack
Basic switching RJ45 Ethernet ports quantity: 24
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
Fiber uplink ports quantity: 4
Gigabit Ethernet (copper) ports quantity: 24
Other features
Size (imperial): 48.3 cm (19")
Authentication method: Login
Logistics data
Harmonized System (HS) code: 851762
Customs product code (TARIC): 8517620000
Data transmission
Switching capacity: 128 Gbit/s
MAC address table: 16000 entries
Packet buffer memory: 1.5 MB
Jumbo frames support: Yes
Forwarding rate: 190.4 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 24
Total Power over Ethernet (PoE) budget: 400 W
Power over Ethernet (PoE) type supported: PoE+
Multicast features
Multicast support: Yes
Sustainability
Doesn't contain: Cadmium, Mercury, Lead
