Opis i karakteristike
Design
Stackable: No
Rack mounting: Yes
Form factor: 1U
Power
Power supply included: Yes
Power source: AC
AC input voltage: 200 240 V
Power consumption note: Max. Power (w/o PoE): 19.7W Max. Power (w/ PoE): 165W
Security
DHCP features: DHCP client
IGMP snooping: Yes
Authentication: MACbased authentication
Access Control List (ACL): Yes
Operational conditions
Storage relative humidity (HH): 15 90%
Operating relative humidity (HH): 15 95%
Operating temperature (TT): 0 40 C
Storage temperature (TT): 40 70 C
Management features
Switch layer: L3
Cloudmanaged: Yes
Switch type: Managed
Webbased management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 44 mm
Depth: 254 mm
Height: 255 mm
Weight: 2.8 kg
Network
VLAN support: Yes
Spanning tree protocol: Yes
Port mirroring: Yes
Link aggregation: Yes
Auto MDI/MDIX: Yes
10G support: No
Flow control support: Yes
Networking standards: IEEE 802.1D, IEEE 802.3at, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3af, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3ad, IEEE 802.1s
Performance
Flash memory: 16384 MB
Builtin processor: Yes
Processor model: ARM CortexA9
Memory type: DDR3SDRAM
Internal memory: 4096 MB
Processor frequency: 1016 MHz
Protocols
IPv6 FIB entries: 128
IPv4 & IPv6 features: IPv4/IPv6 accesscontrol list (ACL)
IPv4 FIB entries: 256
Ports & interfaces
Basic switching RJ45 Ethernet ports quantity: 12
SFP module slots quantity: 2
Console port: USB
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
I/O ports: 12 x 10/100/1000BASET Class 4 PoE ports 2 x 1 G SFP ports 2 x 1 GbE ports Supports PoE Standards IEEE 802.3af, 802.3at 1 x USBC console port 1 x USB TypeA host port
Other features
Latency: 1 Gbps: 2.3 Sec
Memory and processor: CPU: Dualcore Arm CortexA9 @ 1016 MHz Memory: 4 GB DDR3 Flash: 16 GB eMMC
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Packet buffer memory: 12.38 MB
MAC address table: 8192 entries
Static route: Yes
Throughput: 23.8 Mpps
Switching capacity: 32 Gbit/s
Latency (1 Gbps): 2.3 s
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 139 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
