GA-Z790 EAGLE (1700) (D) cijene

Technical details
Warranty period: 3 year(s)

Processor
Processor socket: LGA 1700
Compatible processor series: Intel Core i3 12th Gen, Intel Core i7 13th Gen, Intel Pentium, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Celeron, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i9 14th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen
Processor manufacturer: Intel
Supported processor sockets: LGA 1700

Graphics
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
DirectX version: 12.0
Parallel processing technology support: Not supported

Features
PC health monitoring: Voltage, Water cooling, Fan, Temperature
Audio chip: Realtek ALC897
Product colour: Black
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z790
Component for: PC
Power source type: ATX
Motherboard chipset family: Intel
Windows operating systems supported: Windows 10 x64, Windows 11 x64

Memory
Supported memory clock speeds: 7600, 4400, 6400, 5200, 6800, 5600, 7200 MHz, 6200, 6000, 4800, 6600, 5800, 5400, 7400, 7000
Maximum internal memory: 256 GB
Number of memory slots: 4
Unbuffered memory: Yes
Supported memory types: DDR5SDRAM
Memory slots type: DIMM
Memory channels: Dualchannel
Supported memory clock speed (max): 7600 MHz
ECC ompatibility: ECC & NonECC
Maximum internal memory per slot: 64 GB

Weight & dimensions
Width: 305 mm
Depth: 244 mm
Height: 35 mm

Network
Ethernet LAN: Yes
WiFi: No
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125

Internal I/O
USB 2.0 connectors: 2
RGB LED pin header: Yes
Thunderbolt headers: 2
S/PDIF out connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel audio connector: Yes
ATX Power connector (24pin): Yes
Number of chassis fan connectors: 4
Number of SATA III connectors: 4
EPS power connector (8pin): Yes
TPM connector: Yes
Front panel connector: Yes
CPU fan connector: Yes
Number of water pump connectors: 2
Number of CPU fan connectors: 2
Number of EPS power connectors (8pin): 2
Number of RGB LED pin headers: 2

BIOS
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
ACPI version: 5.0
BIOS type: UEFI AMI

Packaging data
Package weight: 1.79 kg
Package height: 80 mm
Package depth: 270 mm
Package width: 335 mm
Bundled software: Norton Internet Security (OEM version) LAN bandwidth management software

Packaging content
Screws included: Yes
Batteries included: Yes

Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Number of storage drives supported: 7
RAID levels: 10, 5, 0, 1
RAID support: Yes

Rear panel I/O ports
Linein: Yes
Headphone outputs: 1
DisplayPorts quantity: 1
DisplayPort version: 1.2
USB 3.2 Gen 2 (3.1 Gen 2) TypeC ports quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 4
PS/2 ports quantity: 1
HDMI version: 2.1

Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
2nd M.2 largest key size: 2280

Battery
Battery weight: 3 g
Number of battery cells: 1
Battery type: CR2032
Battery technology: LithiumManganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g

Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
