B760 DS3H GEN5 - 1700 ATX motherboard cijene

Technical details
Warranty period: 3 year(s)

Processor
Processor socket: LGA 1700
Compatible processor series: Intel Core i9 14th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i9 13th Gen, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i7 13th Gen, Intel Celeron, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Pentium Gold, Intel Core i7 12th Gen, Intel Core i5 14th Gen
Processor manufacturer: Intel
Supported processor sockets: LGA 1700

Graphics
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2304 pixels
DirectX version: 12.0
HDCP: Yes

Features
Power source type: ATX
PC health monitoring: Fan, Water cooling, Voltage, Temperature
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Motherboard chipset: Intel B760 Express
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Product colour: Dark brown
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Cooling type: Passive

Memory
Unbuffered memory: Yes
Supported memory clock speeds: 4400, 5200, 4800, 5600
Maximum internal memory: 256 GB
Supported memory types: DDR5SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Supported memory clock speed (max): 5600 MHz
Memory channels: Dualchannel
Maximum internal memory per slot: 64 GB
ECC ompatibility: ECC & NonECC

Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm

Network
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
WiFi: No
Ethernet interface type: Gigabit Ethernet

Internal I/O
USB 2.0 connectors: 2
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24pin): Yes
S/PDIF out connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Serial port headers: 1
RGB LED pin header: Yes
12V power connector: Yes
EPS power connector (8pin): Yes
CPU fan connector: Yes
Number of RGB LED pin headers: 4
Number of CPU fan connectors: 2
TPM connector: Yes
Front panel connector: Yes
Number of water pump connectors: 2
Number of chassis fan connectors: 4
Number of EPS power connectors (8pin): 1

BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI

Packaging data
Package weight: 1.5 kg
Package depth: 270 mm
Package height: 80 mm
Package width: 335 mm
Bundled software: Norton Internet Security (OEM version) LAN bandwidth management software

Packaging content
Screws included: Yes
Batteries included: Yes

Storage controllers
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Number of HDDs supported: 4
Number of storage drives supported: 6
RAID levels: 0, 10, 5, 1

Rear panel I/O ports
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
DisplayPort version: 1.2
Headphone outputs: 1
Linein: Yes
USB 3.2 Gen 2x2 TypeC ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 1
HDMI version: 2.1
HDMI ports quantity: 1
PS/2 ports quantity: 1
Microphone in: Yes

Expansion slots
PCI Express x16 (Gen 3.x) slots: 4
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 2
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0

Battery
Number of battery cells: 1
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Battery technology: LithiumManganese Dioxide (LiMnO2)
Battery type: CR2032

Other features
Weight: 1.32 kg

Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
