Opis i karakteristike
Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
Onboard graphics card: No
Features
Motherboard form factor: ATX
Audio chip: Realtek ALC4080
Motherboard chipset family: AMD
Component for: PC
Motherboard chipset: AMD B850
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Product colour: Black
Memory
Supported memory clock speeds: 8400, 4800 MHz, 5600
Maximum internal memory: 256 GB
Memory channels: Dualchannel
Supported memory clock speed (max): 8400 MHz
Memory slots type: DIMM
Number of memory slots: 4
Supported memory types: DDR5SDRAM
ECC ompatibility: NonECC
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Bluetooth: Yes
WiFi standards: 802.11g, 802.11b, WiFi 5 (802.11ac), WiFi 7 (802.11be), WiFi 4 (802.11n), 802.11a, WiFi 6 (802.11ax), WiFi 6E (802.11ax)
Top WiFi standard: WiFi 7 (802.11be)
Ethernet LAN: Yes
Bluetooth version: 5.4
Ethernet interface type: 5 Gigabit Ethernet
WiFi: Yes
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
CPU fan connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Total number of SATA connectors: 4
RGB LED pin header: Yes
Number of RGB LED pin headers: 3
Number of water pump connectors: 1
Number of CPU fan connectors: 6
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
ACPI version: 6.5
System Management BIOS (SMBIOS) version: 3.7
Storage controllers
Supported storage drive interfaces: M.2, Micro SATA III
RAID levels: 10, 1, 0
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of storage drives supported: 8
Number of HDDs supported: 4
Rear panel I/O ports
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 4
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) TypeC ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 2
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 4
4th M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 4.0
4th M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 22110
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
