Opis i karakteristike
Technical details
Sustainability certificates: Federal Communications Commission (FCC), EuP, CE, ErP
Sustainability compliance: Yes
Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold, Intel Celeron G
Processor manufacturer: Intel
Processor socket: LGA 1700
Graphics
Parallel processing technology support: CrossFire
HDCP: Yes
Maximum resolution: 7680 x 4320 pixels
Graphics card: Intel Iris Xe Graphics
Graphics card family: Intel
Features
Audio chip: Realtek ALC4082
Audio output channels: 7.1 channels
Product colour: Black
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset: Intel Z790
Motherboard form factor: ATX
Motherboard chipset family: Intel
Memory
Unbuffered memory: Yes
Maximum internal memory: 192 GB
Supported memory clock speed (max): 8000 MHz
Memory slots type: DIMM
Supported memory types: DDR5SDRAM
Memory channels: Dualchannel
Number of memory slots: 4
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
LAN controller: Killer E3100G
Bluetooth: Yes
Top WiFi standard: WiFi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
WiFi standards: WiFi 5 (802.11ac), WiFi 7 (802.11be), 802.11a, WiFi 6 (802.11ax), 802.11g, WiFi 4 (802.11n), 802.11b
WiFi: Yes
Ethernet LAN: Yes
Bluetooth version: 5.4
Internal I/O
ATX Power connector (24pin): Yes
USB 2.0 connectors: 2
Thunderbolt headers: 1
Number of SATA III connectors: 4
CPU fan connector: Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
TPM connector: Yes
Number of chassis fan connectors: 5
RGB LED pin header: Yes
12V power connector: Yes
USB 3.2 Gen 2x2 connectors: 1
BIOS
Clear CMOS button: Yes
BIOS type: UEFI AMI
Bundled software: ASRock Motherboard Utility (Phantom Gaming Tuning) Killer Control Center ASRock Polychrome SYNC
Packaging content
Cables included: SATA
Antenna included: Yes
Screws included: Yes
M.2 standoff included: Yes
Storage controllers
RAID levels: 5, 0, 1, 10
Supported storage drive interfaces: M.2
RAID support: Yes
Number of storage drives supported: 6
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 3
USB connector type: USB TypeA, USB TypeC
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 4
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
Ethernet LAN (RJ45) ports: 1
S/PDIF out port: Yes
HDMI version: 2.1
Microphone in: Yes
WiFiAP antenna jack: 2
HDMI ports quantity: 1
USB 3.2 Gen 2x2 TypeC ports quantity: 1
Expansion slots
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
