Opis i karakteristike
Processor
Compatible processor series: AMD Ryzen 7000 Series
Maximum number of SMP processors: 1
Processor manufacturer: AMD
Processor socket: Socket AM5
Features
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset: AMD B650
Motherboard chipset family: AMD
Motherboard form factor: MiniITX
Memory
Maximum internal memory: 96 GB
Memory slots type: DIMM
Number of memory slots: 2
Supported memory types: DDR5SDRAM
Memory channels: Dualchannel
Unbuffered memory: Yes
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
Bluetooth: Yes
Top WiFi standard: WiFi 6E (802.11ax)
LAN controller: Dragon RTL8125BG
WiFi standards: 802.11a, 802.11g, WiFi 6E (802.11ax), WiFi 5 (802.11ac), 802.11b, WiFi 4 (802.11n)
WiFi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Bluetooth version: 5.2
Internal I/O
USB TypeC socket on the front panel: Y
ATX Power connector (24pin): Yes
Front panel audio connector: Yes
Number of SATA III connectors: 2
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8pin): Yes
RGB LED pin header: Yes
USB 2.0 connectors: 1
BIOS
BIOS type: UEFI AMI
Storage controllers
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 10, 1
Number of storage drives supported: 4
Rear panel I/O ports
WiFi antenna socket: Yes
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 3
HDMI ports quantity: 1
Linein: Yes
BIOS switch button: Yes
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) TypeC ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 4.x) slots: 1
