Opis i karakteristike
Processor
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Maximum number of SMP processors: 1
Processor manufacturer: AMD
Processor socket: Socket AM5
Features
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870
Motherboard chipset family: AMD
Audio chip: Realtek ALC4082
Operating system architecture: 64bit
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: ATX
Memory
Memory slots type: DIMM
Unbuffered memory: Yes
Supported memory types: DDR5SDRAM
Memory channels: Dualchannel
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8200+ MHz
Number of memory slots: 4
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
WiFi standards: WiFi 6E (802.11ax), WiFi 5 (802.11ac), WiFi 7 (802.11be), 802.11a, WiFi 4 (802.11n), 802.11g, 802.11b
WiFi: Yes
Bluetooth: Yes
Ethernet LAN: Yes
LAN controller: Realtek RTL8126
Bluetooth version: 5.4
Ethernet interface type: 5 Gigabit Ethernet
Top WiFi standard: WiFi 7 (802.11be)
Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
ATX Power connector (24pin): Yes
RGB LED pin header: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Storage controllers
Supported storage drive interfaces: Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4)
Rear panel I/O ports
Clear CMOS button: Yes
Ethernet LAN (RJ45) ports: 1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 3
Lineout: Yes
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 5
S/PDIF out port: Yes
HDMI ports quantity: 1
USB 2.0 connectors: 2
USB 3.2 Gen 2x2 TypeC ports quantity: 2
WiFi antenna socket: Yes
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
