Opis i karakteristike
Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
Maximum resolution: 3840 x 2160 pixels
HDCP: Yes
Parallel processing technology support: Not supported
Certification: FCC, CE, ErP/EuP
Features
Audio chip: Realtek ALC897
Product colour: Black
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Motherboard chipset: AMD B850
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory
Maximum internal memory: 128 GB
Number of memory slots: 2
Supported memory types: DDR5SDRAM
Memory slots type: DIMM
Memory channels: Dualchannel
ECC ompatibility: ECC & NonECC
Weight & dimensions
Depth: 226 mm
Width: 244 mm
Network
LAN controller: Dragon RTL8125BG
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Mobile network connection: No
WiFi: No
Internal I/O
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24pin): Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
TPM connector: Yes
Number of chassis fan connectors: 3
RGB LED pin header: Yes
USB TypeC ports quantity: 1
EPS power connector (8pin): Yes
Number of CPU fan connectors: 2
12V power connector: Yes
Number of RGB LED pin headers: 1
Number of EPS power connectors (8pin): 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Screws included: Yes
Storage controllers
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 1, 10, 0
Rear panel I/O ports
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
DisplayPorts quantity: 1
Linein: Yes
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 3
Microphone in: Yes
Audio output: 3.5 mm
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeC ports quantity: 1
HDMI version: 2.1
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 1
Number of M.2 (E) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
