Opis i karakteristike
Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Parallel processing technology support: Not supported
Certification: FCC, CE, ErP/EuP ready
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset: AMD B850
Product colour: Black
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Audio chip: Realtek ALC897
Memory
Maximum internal memory: 256 GB
Memory channels: Dualchannel
Unbuffered memory: Yes
Number of memory slots: 4
Supported memory types: DDR5SDRAM
Memory slots type: DIMM
ECC ompatibility: ECC & NonECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
WiFi standards: WiFi 5 (802.11ac), 802.11a, WiFi 6 (802.11ax), WiFi 4 (802.11n), WiFi 6E (802.11ax), 802.11g, 802.11b
Bluetooth: Yes
LAN controller: Dragon RTL8125BG
Ethernet LAN: Yes
WiFi: Yes
Top WiFi standard: WiFi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.2
Internal I/O
Number of SATA III connectors: 4
CPU fan connector: Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
EPS power connector (8pin): Yes
TPM connector: Yes
Number of chassis fan connectors: 3
ATX Power connector (24pin): Yes
USB 2.0 connectors: 2
RGB LED pin header: Yes
12V power connector: Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
Number of EPS power connectors (8pin): 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
RAID support: Yes
RAID levels: 0, 10, 1
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports
HDMI version: 2.1
HDMI ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 1
DisplayPort version: 1.4
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 2
USB connector type: USB TypeC, USB TypeA
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) TypeC ports quantity: 1
Linein: Yes
WiFiAP antenna jack: 2
Headphone outputs: 3
Expansion slots
Number of M.2 (M) slots: 3
3rd M.2 largest key size: 2280
PCI Express x4 (Gen 4.x) slots: 1
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 highest PCI Express generation: 5.0
3rd M.2 highest PCI Express generation: 4.0
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
