Opis i karakteristike
Design
International Protection (IP) code: IP30
Rack mounting: No
Product colour: Black
Housing material: Metal
LED indicators: Yes
DIN rail mounting: Yes
Power
Power consumption (max): 12 W
DC input voltage: 12 60 V
Security
Security algorithms: SNMPv3, SNMP, SSH2
IGMP snooping: Yes
Queue scheduling algorithms: WFQ, SP, Weighted Round Robin (WRR)
BPDU filtering/protection: Yes
DHCP features: DHCP snooping, DHCP server, DHCP relay
Access Control List (ACL): Yes
Operational conditions
Operating temperature (TT): 40 75 C
Operating relative humidity (HH): 0 95%
Management features
Webbased management: Yes
Quality of Service (QoS) support: Yes
MIB support: II RFC 1213, RFC 1493
Switch layer: L2
System event log: Yes
Switch type: Managed
Weight & dimensions
Weight: 884 g
Width: 160 mm
Depth: 120 mm
Height: 50 mm
Network
Networking standards: IEEE 802.1x, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3u, IEEE 802.3ad, IEEE 802.3az, IEEE 802.1D, IEEE 802.1AX, IEEE 802.1p, IEEE 802.1ab, IEEE 802.1w
10G support: No
Full duplex: Yes
Number of VLANs: 4094
VLAN support: Yes
Port mirroring: Yes
Virtual LAN features: Tagged VLAN, MAC addressbased VLAN
Link aggregation: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Performance
Mean time between failures (MTBF): 1072674 h
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 16
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 32 Gbit/s
Jumbo frames support: Yes
Packet buffer memory: 128 MB
MAC address table: 8000 entries
Storeandforward: Yes
Jumbo frames: 10000
Forwarding rate: 23.8 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Multicast MAC address table: 256 entries
