Opis i karakteristike
Technical details
Warranty period: 8 year(s)
Design
Product colour: Black, White
Cooling type: Active
Number of fans: 1 fan(s)
Fan diameter: 12 cm
On/off switch: Yes
Power
Input current: 10 A
Power protection features: Overheating, Short circuit, Over power, Overcharge, Over current
AC input voltage: 200 240 V
Max output current (12V): 0.3 A
AC input frequency: 50/60 Hz
Combined power (12V): 3.6 W
Combined power (+3.3V): 100 W
Max output current (+12V): 62 A
Combined power (+5Vsb): 12.5 W
Combined power (+5V): 100 W
Maximum input current (@220V): 10 A
Max output current (+5Vsb): 2.5 A
Combined power (+12V): 744 W
Total power: 750 W
Max output current (+3.3V): 20 A
Max output current (+5V): 20 A
Weight & dimensions
Width: 140 mm
Weight: 1.4 kg
Depth: 150 mm
Height: 86 mm
Performance
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Purpose: PC
Packaging data
Package weight: 3.2 kg
Package type: Box
Ports & interfaces
Peripheral (Molex) power connectors (4pin): 2
Motherboard power connector: 18+10 pin ATX
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 4
PCI Express power connectors (6+2 pin): 4
Cabling type: FullyModular
Safety warning
Hazard pictogram(s): GHS02: Flammable, GHS07: Harmful, GHS09: Environmental hazard
