Gigabyte P550SS power supply unit 550 W 20+4 pin ATX ATX Black cijene

Design
Fan location: Top
On/off switch: Yes
Cooling type: Active
Fan diameter: 12 cm
Product colour: Black
Number of fans: 1 fan(s)

Power
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power
Efficiency: 90%
AC input voltage: 155240 V
Input current: 6.3 A
Combined power (+3.3V): 100 W
AC input frequency: 50/60 Hz
Total power: 550 W
Power Factor Correction (PFC) type: Active
Combined power (+12V): 549.6 W
Hold time: 16 ms
Combined power (+5Vsb): 15 W
Power Good signal delay range: 100 150 ms
Combined power (+5V): 100 W
Max output current (+5Vsb): 3 A
Combined power (12V): 3.6 W
Max output current (+12V): 45.8 A
Max output current (12V): 0.3 A
Max output current (+3.3V): 20 A
Max output current (+5V): 20 A

Weight & dimensions
Depth: 150 mm
Width: 140 mm
Weight: 1.86 kg
Height: 86 mm

Performance
ATX version: 3.1
Bearing technology: Ball bearing
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Silver
Purpose: PC
Mean time between failures (MTBF): 100000 h

Packaging data
Package depth: 206 mm
Package height: 117 mm
Package type: Box
Package width: 254 mm
Package weight: 2.32 kg

Ports & interfaces
Peripheral (Molex) power connectors (4pin): 4
Floppy disk drive connector: Yes
Cabling type: NonModular
PCI Express power connectors (6+2 pin): 2
ATX power connector (20+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 5
Floppy drive power connector: 2
Motherboard power cable length: 60 cm
PCI Express connector: Yes

Logistics data
Warranty period: 3 year(s)
