Opis i karakteristike
Technical details
Sustainability certificates: RoHS
Design
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Cooling type: Active
On/off switch: Yes
Product colour: Grey
Fan location: Top
Power
Peak power: 550 W
Power protection features: Over current, Overheating, Over power, Short circuit, Over voltage
Max output current (+5V): 36 A
Max output current (+3.3V): 33 A
AC input voltage: 230 V
Max output current (+12V): 24 A
Combined power (+3.3V): 280 W
Combined power (+5V): 280 W
Max output current (12V): 0.5 A
Combined power (+5Vsb): 18.5 W
Max output current (+5Vsb): 2.5 A
Combined power (12V): 18.5 W
Total power: 550 W
Input current: 5 A
Efficiency: 70%
Combined power (+12V): 288 W
Operational conditions
Operating temperature (TT): 5 50 C
Weight & dimensions
Weight: 1.04 kg
Height: 85 mm
Width: 150 mm
Depth: 140 mm
Certification: CE, REACH
Performance
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Supported motherboard form factors: ATX
ATX version: 2.31
Purpose: PC
Packaging data
Package width: 160 mm
Package weight: 1.12 kg
Package depth: 220 mm
Package type: Box
Manual: Yes
Package height: 95 mm
Ports & interfaces
Cabling type: NonModular
PCI Express power connectors (6pin): 1
CPU P4 connector (4pin): 1
Number of SATA power connectors: 3
Peripheral (Molex) power cable length: 300 mm
SATA power cable length: 300 mm
Motherboard power connector: 20+4 pin ATX
CPU power cable length: 45 cm
Peripheral (Molex) power connectors (4pin): 2
Other features
Warranty card: Yes
