Technical details
Sustainability certificates: RoHS
Design
Product colour: Grey
Power
AC input voltage: 230 V
Power protection features: Short circuit, Over voltage, Under voltage, Over current, Over power
Max output current (+12V): 19 A
Combined power (+5V): 210 W
Combined power (+3.3V): 210 W
Combined power (12V): 18.5 W
Combined power (+5Vsb): 18.5 W
Max output current (+5Vsb): 2.5 A
Input current: 5 A
Max output current (+5V): 28 A
Total power: 420 W
Efficiency: 70%
Max output current (+3.3V): 24 A
Max output current (12V): 0.5 A
AC input frequency: 50 Hz
Combined power (+12V): 228 W
Operational conditions
Operating temperature (TT): 5 50 C
Weight & dimensions
Height: 85 mm
Depth: 140 mm
Weight: 1.04 kg
Width: 150 mm
Certification: REACH, CE
Performance
ATX version: 2.31
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Purpose: PC
Packaging data
Package width: 151 mm
Package weight: 1.05 kg
Package depth: 196 mm
Package type: Box
Package height: 86 mm
Ports & interfaces
Number of SATA power connectors: 3
CPU P4 connector (4pin): 1
ATX Power connector (20pin): Y
Motherboard power connector: 20+4 pin ATX
Peripheral (Molex) power connectors (4pin): 2
