Opis i karakteristike
Design
Product colour: Black
Reset button: Yes
Form factor: 1U
Housing material: Metal
Rack mounting: Yes
Number of fans: 1 fan(s)
Power
AC input frequency: 50/60 Hz
Power consumption (max): 55 W
AC input voltage: 100 240 V
Power supply included: Yes
Power source: AC
Security
SSH/SSL support: Yes
Authentication: Guest VLAN
DHCP features: DHCP snooping, DHCP Option 66, DHCP server, DHCP Option 82, DHCP Option 67, DHCP client, DHCP relay
IGMP snooping: Yes
IGMP proxy: Yes
Authentication type: RADIUS, TACACS+
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (HH): 10 90%
Operating temperature (TT): 0 40 C
Heat dissipation: 188 BTU/h
Management features
Webbased management: Yes
Configuring Location Settings (CLI): Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Height: 44 mm
Depth: 300 mm
Width: 442 mm
Weight: 4.1 kg
Network
Networking standards: IEEE 802.3ad, IEEE 802.1s, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.3u, IEEE 802.1w, IEEE 802.3az, IEEE 802.1x, IEEE 802.1ab, IEEE 802.3ae
Cable length detection: Yes
Virtual LAN features: Tagged VLAN, MAC addressbased VLAN, Portbased VLAN, VLAN Identifier ( VLAN ID), MVRP, IP subnetbased VLAN, Private VLAN
Port mirroring: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Flow control support: Yes
10G support: Yes
VLAN support: Yes
Number of VLANs: 4096
Link aggregation: Yes
Rate limiting: Yes
Performance
Noise level: 45 dB
Firmware upgradeable: Yes
Packaging data
Package weight: 5.52 kg
Package height: 100 mm
Package width: 470 mm
Mounting brackets included: Yes
Package depth: 534 mm
Packaging content
Cables included: Serial, AC
Quick start guide: Yes
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC)
Protocols
IP Source Guard (IPSG): Yes
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Console port: RJ45
Power connector: ACin jack
Basic switching RJ45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Basic switching RJ45 Ethernet ports quantity: 48
SFP+ module slots quantity: 4
2.5G Ethernet (copper) ports quantity: 12
Gigabit Ethernet (copper) ports quantity: 36
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Jumbo frames: 10240
Switching capacity: 212 Gbit/s
MAC address table: 32000 entries
Static route: Yes
Packet buffer memory: 4 MB
Number of static routes: 128
Storeandforward: Yes
Jumbo frames support: Yes
Throughput: 130 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Number of multicast groups filtered: 1024
Multicast Listener Discovery (MLD) snooping: Y
