Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 4000 Series, AMD Ryzen 5000 Series, AMD Ryzen 3000 Series
Supported processor sockets: Socket AM4
Processor socket: Socket AM4
Processor manufacturer: AMD
Graphics
DirectX version: 12.0
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 5120 x 2880 pixels
Features
Product colour: Dark brown
Motherboard chipset: AMD B550
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Component for: PC
Audio chip: Realtek ALC1220VB
PC health monitoring: Fan, Voltage, Temperature
Motherboard form factor: micro ATX
Cooling type: Passive
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Power source type: ATX
Memory
Unbuffered memory: Yes
Supported memory clock speeds: 4133, 4000 MHz, 2400, 3400, 3866, 2133, 3200, 4266, 2933, 3600, 4733, 4600, 2667, 3733, 4400, 3466
Maximum internal memory: 128 GB
Memory channels: Dualchannel
Supported memory clock speed (max): 4733 MHz
Memory slots type: DIMM
Number of memory slots: 4
Supported memory types: DDR4SDRAM
Maximum internal memory per slot: 32 GB
ECC ompatibility: ECC & NonECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Height: 35 mm
Network
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
WiFi: No
Ethernet interface type: Gigabit Ethernet
Internal I/O
Front panel connector: Yes
EPS power connector (8pin): Yes
TPM connector: Yes
Number of chassis fan connectors: 2
USB 2.0 connectors: 1
Front panel audio connector: Yes
ATX Power connector (24pin): Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
Serial port headers: 1
RGB LED pin header: Yes
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 5
Number of EPS power connectors (8pin): 1
BIOS
ACPI version: 5.0
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
BIOS memory size: 128 Mbit
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
Packaging data
Package height: 54 mm
Package width: 265 mm
Package depth: 265 mm
Package weight: 947 g
Bundled software: Norton Internet Security (OEM version) LAN bandwidth management software
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of storage drives supported: 6
Number of HDDs supported: 4
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 3.0, PCI Express 4.0, SATA III
RAID levels: 1, 10, 0
Rear panel I/O ports
HDMI version: 2.1
PS/2 ports quantity: 1
Microphone in: Yes
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 4
HDMI ports quantity: 1
Linein: Yes
DisplayPort version: 1.4
Ethernet LAN (RJ45) ports: 1
DisplayPorts quantity: 1
USB 2.0 ports quantity: 2
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
PCI Express x1 (Gen 3.x) slots: 1
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 3.0
Battery
Battery technology: LithiumManganese Dioxide (LiMnO2)
Battery type: CR2032
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery weight: 3 g
Other features
Weight: 870 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
