Gigabyte B760M GP Wifi DDR4 (B760.S1700.mATX.DDR4) cijene

Technical details
Warranty period: 3 year(s)

Processor
Supported processor sockets: LGA 1700
Maximum internal memory supported by processor: 128 GB
Processor socket: LGA 1700
Compatible processor series: Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i9 13th Gen, Intel Celeron, Intel Pentium, Intel Core i3 13th Gen, Intel Core i3 12th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 13th Gen, Intel Core i9 14th Gen, Intel Core i3 14th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen
Processor manufacturer: Intel

Graphics
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
HDCP: Yes
DirectX version: 12.0

Features
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset: Intel B760
Power source type: ATX
Component for: PC
Motherboard form factor: micro ATX
PC health monitoring: Temperature, Fan, Voltage, Water cooling
Product colour: Grey
Audio chip: Realtek ALC897

Memory
ECC ompatibility: ECC & NonECC
Maximum internal memory per slot: 32 GB
Unbuffered memory: Yes
Supported memory clock speeds: 4600, 3200, 2666, 4266, 3466, 2133, 4133, 4000, 3666, 4800, 4933, 3000, 5333 MHz, 4500, 2400, 4700, 3733, 4300, 4400, 5000, 3800, 3333, 2933, 3600, 3300, 5133, 3400, 3866
Maximum internal memory: 128 GB
Memory channels: Dualchannel
Supported memory clock speed (max): 5333 MHz
Supported memory types: DDR4SDRAM
Memory slots type: DIMM
Number of memory slots: 4

Weight & dimensions
Width: 244 mm
Height: 35 mm
Depth: 244 mm

Network
Bluetooth version: 5.3
LAN controller: Realtek RTL8111H
Bluetooth: Yes
WLAN controller model: Realtek RTL8851BE
Top WiFi standard: WiFi 6 (802.11ax)
WiFi standards: WiFi 4 (802.11n), 802.11b, 802.11a, WiFi 6 (802.11ax), 802.11g, WiFi 5 (802.11ac)
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
WiFi: Yes

Internal I/O
Number of CPU fan connectors: 1
Number of EPS power connectors (8pin): 1
Number of RGB LED pin headers: 2
Front panel audio connector: Yes
Number of chassis fan connectors: 3
TPM connector: Yes
Parallel connector: Yes
S/PDIF out connector: Yes
EPS power connector (8pin): Yes
Number of SATA III connectors: 4
CPU fan connector: Yes
USB 2.0 connectors: 2
Front panel connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Serial port headers: 1
RGB LED pin header: Yes
ATX Power connector (24pin): Yes

BIOS
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 128 Mbit
ACPI version: 5.0
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes

Packaging data
Package depth: 268 mm
Package width: 270 mm
Package weight: 1.2 kg
Package height: 68 mm
Bundled software: Norton Internet Security (OEM version) LAN bandwidth management software

Packaging content
Screws included: Yes
Antenna included: Yes
Batteries included: Yes

Storage controllers
RAID levels: 5, 1, 10, 0
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 4
Number of storage drives supported: 6

Rear panel I/O ports
Ethernet LAN (RJ45) ports: 1
Linein: Yes
USB 2.0 ports quantity: 2
DisplayPorts quantity: 1
WiFiAP antenna jack: 2
DisplayPort version: 1.2
HDMI ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 3
PS/2 ports quantity: 1
Headphone outputs: 1

Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
Number of M.2 (M) slots: 2
1st M.2 highest PCI Express generation: 4.0

Battery
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery weight: 3 g
Battery type: CR2032
Battery technology: LithiumManganese Dioxide (LiMnO2)

Other features
Weight: 1.1 kg

Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
