Technical details
Sustainability certificates: RoHS
Design
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Product colour: Grey
Power
Combined power (+5V): 300 W
Max output current (+3.3V): 35 A
Total power: 600 W
Power protection features: Over power, Under voltage, Over current, Short circuit, Over voltage
Max output current (+5V): 38 A
Combined power (+5Vsb): 18.5 W
Power Factor Correction (PFC) type: Passive
Efficiency: 70%
Max output current (+12V): 36 A
Combined power (+3.3V): 300 W
Combined power (+12V): 312 W
AC input frequency: 50 Hz
Combined power (12V): 18.5 W
Max output current (+5Vsb): 2.5 A
AC input voltage: 230 V
Input current: 5 A
Max output current (12V): 0.5 A
Operational conditions
Operating temperature (TT): 5 50 C
Weight & dimensions
Width: 150 mm
Depth: 140 mm
Weight: 1.12 kg
Height: 87 mm
Certification: REACH, CE, RoHS
Performance
Power supply unit (PSU) form factor: ATX
ATX version: 2.31
Mean time between failures (MTBF): 100000 h
Purpose: PC
Packaging data
Package type: Box
Package depth: 220 mm
Package weight: 1.19 kg
Package height: 95 mm
Package width: 160 mm
Ports & interfaces
PCI Express power connectors (6+2 pin): 1
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 4
EPS power connector (8pin): No
Peripheral (Molex) power connectors (4pin): 2
