Opis i karakteristike
Design
DIN rail mounting: Yes
International Protection (IP) code: IP30
Product colour: Black
LED indicators: Yes
Wall mountable: Yes
Rack mounting: No
Housing material: Metal
Power
Redundant power supply (RPS) support: Yes
Input voltage: 48 56 V
Power consumption (max): 5.76 W
Power protection features: Overload
Operational conditions
Operating temperature (TT): 40 75 C
Management features
Switch layer: L2
Switch type: Unmanaged
Weight & dimensions
Depth: 105 mm
Height: 36 mm
Width: 143 mm
Weight: 514 g
Network
Networking standards: IEEE 802.3u, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
10G support: No
Copper ethernet cabling technology: 10BASET, 100BASETX, 1000BASET
Flow control support: Yes
Autonegotiation: Yes
MAC address autoaging supported: Yes
Full duplex: Yes
MAC address autolearning supported: Yes
Packaging data
Terminal block included: Yes
Mounting brackets included: Yes
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Basic switching RJ45 Ethernet ports quantity: 4
Gigabit Ethernet (copper) ports quantity: 4
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames: 9000
Switching capacity: 12 Gbit/s
Throughput: 8.9 Mpps
MAC address table: 1024 entries
Storeandforward: Yes
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet plus (PoE+) ports quantity: 4
