Opis i karakteristike
Design
International Protection (IP) code: IP30
Product colour: Black
Rack mounting: No
Housing material: Metal
LED indicators: Yes
DIN rail mounting: Yes
Power
AC input frequency: 50 60 Hz
Input voltage: 48 56 V
Power source: DC/PoE
Power consumption (max): 6.2 W
AC input voltage: 100 240 V
Input current: 2 A
Operational conditions
Operating temperature (TT): 40 75 C
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 158 mm
Width: 122 mm
Weight: 630 g
Depth: 48 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3af, IEEE 802.3x, IEEE 802.3u, IEEE 802.3bz
Full duplex: Yes
10G support: No
Copper ethernet cabling technology: 100BASETX, 10BASET, 1000BASET
MAC address autoaging supported: Yes
Flow control support: Yes
MAC address autolearning supported: Yes
Autonegotiation: Yes
Performance
Mean time between failures (MTBF): 510304 h
Packaging content
Quick start guide: Yes
Certification: FCC IEC 60068227 IEC 60068232 IEC 6006826 IEC 6100042 IEC 6100044 IEC 6100045
Certificates
Compliance certificates: CE
Ports & interfaces
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 10
Combo SFP ports quantity: 2
Gigabit Ethernet (copper) ports quantity: 10
Data transmission
MAC address table: 11000 entries
Jumbo frames support: Yes
Packet buffer memory: 2 MB
Switching capacity: 20 Gbit/s
Storeandforward: Yes
Jumbo frames: 10000
Forwarding rate: 8.9 Mpps
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 360 W
Power over Ethernet (PoE): Yes
Power over Ethernet 4PPoE (PoE++) ports quantity: 4
Power over Ethernet plus (PoE+) ports quantity: 4
Sustainability
Sustainability compliance: Yes
