Design
Number of fans: 4 fan(s)
Product colour: Black
LED indicators: Yes
Form factor: 1U
Rack mounting: Yes
Stackable: Yes
Power
AC input voltage: 100 240 V
Power consumption (max): 1767.7 W
AC input frequency: 50/60 Hz
Power source: AC
Power supply included: Yes
Security
IGMP snooping: Yes
Loop protection: Yes
DHCP features: DHCP snooping, DHCP relay, DHCPv6 snooping
SSH/SSL support: Yes
Access Control List (ACL): Yes
Authentication type: RADIUS
IGMP entries: 2048
Authentication: Auto VLAN, MACbased authentication, Portbased authentication
Operational conditions
Operating temperature (TT): 5 40 C
Operating relative humidity (HH): 10 90%
Storage temperature (TT): 40 70 C
Storage relative humidity (HH): 5 90%
Heat dissipation: 6027.86 BTU/h
Management features
Quality of Service (QoS) support: Yes
Webbased management: Yes
Switch layer: L3
Cloudmanaged: Yes
Switch type: Managed
Configuring Location Settings (CLI): Yes
System event log: Yes
ARP inspection: Yes
Weight & dimensions
Width: 440 mm
Height: 44 mm
Depth: 420 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
VLAN support: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1p
10G support: No
Spanning tree protocol: Yes
Port mirroring: Yes
Virtual LAN features: Multicast VLAN, Private VLAN, MAC addressbased VLAN, Voice VLAN
Number of VLANs: 4000
Rate limiting: Yes
Flow control support: Yes
Broadcast storm control: Yes
IP routing: Yes
Packaging content
Manual: Yes
Cables included: LAN (RJ45), AC
Ports & interfaces
USB 2.0 ports quantity: 2
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 48
SFP+ module slots quantity: 6
Console port: RJ45/USB TypeC
Data transmission
Jumbo frames support: Yes
Switching capacity: 216 Gbit/s
Jumbo frames: 9000
Packet buffer memory: 3 MB
MAC address table: 32000 entries
Forwarding rate: 160.7 Mpps
Static route: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 1440 W
Power over Ethernet plus (PoE+) ports quantity: 48
Multicast features
Multicast support: Yes
