Opis i karakteristike
Design
Housing material: Aluminium
Device type: Cellular network gateway
LED indicators: Status, LAN, Signal strength, Power
Suitable for indoor use: Yes
Mounting: DINrail/Wall mounting
Market positioning: Industrial
Product colour: Black
Power
External power adapter: Yes
Input voltage: 9 30 V
Power source type: DC
Security
DMZ support: Yes
Port forwarding: Yes
Operational conditions
Operating temperature (TT): 40 75 C
Operating relative humidity (HH): 10 90%
Management features
Management platform: RMS
Weight & dimensions
Height: 25 mm
Width: 83 mm
Weight: 165 g
Depth: 74.2 mm
Performance
Internal storage capacity: 0.016 GB
RAM type: DDR2
Antennas quantity: 2
GPS (satellite): Yes
Antenna type: External
Processor frequency: 0.58 GHz
RAM capacity: 0.128 GB
Antenna connector type: SMA
Builtin processor: Yes
Webbased management: Yes
Processor manufacturer: MediaTek
Wireless LAN features
WiFi: No
Ports & interfaces
Serial interface type: RS232/485, RS232
Ethernet LAN (RJ45) ports: 1
Serial ports quantity: 1
GPS Performance
QuasiZenith Satellite System (QZSS): Yes
Galileo: Yes
BeiDou: Yes
GLONASS: Yes
Embedded GNSS: Yes
Mobile network
Data network: LTE, 4G, 3G, 2G
SIM card type: MiniSIM
Data transfer rate (LTE) (upload): 50 Mbit/s
Number of SIM cards: 2
Short Message Service (SMS): Yes
SIM interface: 3 V
Data transfer rate (LTE) (download): 150 Mbit/s
Ethernet LAN features
Full duplex: Yes
Ethernet LAN data rates: 10, 100
Auto MDI/MDIX: Yes
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.11e, IEEE 802.3az
Ethernet LAN interface type: Fast Ethernet
Ethernet LAN: Yes
DHCP server: Yes
Serial interface
RS232 signals: CTS, Rx, Tx, RTS
RS485 signals: RDB+, Data, RDA, Data+
