Opis i karakteristike
Features
LED indicators: Yes
Product colour: Black
Internal: No
Power
Input current: 1 A
Input voltage: 5 V
Operational conditions
Storage temperature (TT): 20 70 C
Operating relative humidity (HH): 5 90%
Operating temperature (TT): 0 50 C
Weight & dimensions
Weight: 200 g
Height: 26 mm
Depth: 71 mm
Width: 94 mm
Network
Maximum data transfer rate: 100 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3x, IEEE 802.3u
Auto MDI/MDIX: Yes
Copper ethernet cabling technology: 10BASET, 100BASETX
Duplex system: Full
Converter input interface: 10BaseT, 100BaseTX
Fiber ethernet cabling technology: 100BASEFX
Ethernet LAN data rates: 10, 100
Flow control support: Yes
Converter output interface: 100BaseFX
Ethernet interface type: Fast Ethernet
Autonegotiation: Yes
Storeandforward: Yes
Performance
Fiber cable diameters supported (core/cladding): 62.5/125 m, 50/125
Mean time between failures (MTBF): 100000 h
Wavelength: 1310 nm
Fiber mode structure: Multimode
Maximum transfer distance: 2000 m
Packaging data
Package weight: 300 g
Package width: 230 mm
Package depth: 150 mm
Package type: Box
Package height: 58 mm
Packaging content
Quick installation guide: Yes
AC adapter included: Yes
Certification: CE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Fiber optic connector: SC
Ethernet LAN (RJ45) ports: 1
Fiber ports quantity: 1
DCin jack: Yes
Connectivity technology: Wired
Logistics data
Country of origin: China
Products per master (outer) case: 40 pc(s)
Master (outer) case height: 305 mm
Master (outer) case gross weight: 32 kg
Master (outer) case length: 420 mm
Master (outer) case width: 440 mm
Harmonized System (HS) code: 85176990
