Planet XT-705A network media converter 10000 Mbit /s Multi-mode, Single-mode cijene

Features
Housing material: Metal
LED indicators: Power, Link
DIN rail mounting: Yes
Internal: No

Power
Input current: 2 A
Input voltage: 5 V
Power consumption (typical): 26 W

Operational conditions
Storage relative humidity (HH): 5 95%
Operating relative humidity (HH): 5 95%
Operating temperature (TT): 0 50 C
Storage temperature (TT): 10 70 C

Weight & dimensions
Weight: 180 g
Height: 26 mm
Depth: 70 mm
Width: 94 mm

Network
Cable types supported: Cat5, Cat5e, Cat6, Cat7, Cat6a
Networking standards: IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3x, IEEE 802.3an, IEEE 802.3u, IEEE 802.3bz
Ethernet interface type: Fast Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Gigabit Ethernet
Autonegotiation: Yes
Storeandforward: Yes
Maximum data transfer rate: 10000 Mbit/s
Auto MDI/MDIX: Yes
Flow control support: Yes
Duplex system: Half, Full
Jumbo frames support: Yes
Jumbo frames: 16000
Fiber ethernet cabling technology: 10GBASEX

Performance
Fiber cable diameters supported (core/cladding): 9/125 m, 62.5/125 m, 50/125 m
Maximum transfer distance: 60000 m
Fiber mode structure: Singlemode, Multimode

Ports & interfaces
Ethernet LAN (RJ45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: SFP+
Connectivity technology: Wired

Logistics data
Harmonized System (HS) code: 85176990
