Technical details
Package volume: 3399.38 cm
Features
Consumer Electronics Control (CEC) support: Yes
Bidirectional: Yes
Electrostatic Discharge (ESD) protection: Yes
Type: AV transmitter & receiver
HDCP version: 1.4/2.2
Plug and Play: Yes
Material: Metal
Bandwidth: 18 Gbit/s
Maximum transfer distance: 150 m
Cable types supported: Cat6, Cat7, Cat8, Cat5e
Wall mountable: Yes
Product colour: Black
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Power
Operating voltage: 24 V
Power consumption (typical): 9.36 W
Power over Ethernet (PoE): No
Input current: 1 A
Operational conditions
Operating temperature (TT): 0 40 C
Weight & dimensions
Transmitter weight: 160 g
Receiver dimensions (WxDxH): 65 x 140 x 18 mm
Transmitter dimensions (WxDxH): 65 x 140 x 18 mm
Receiver weight: 155 g
Packaging data
Package weight: 1 kg
Package depth: 185 mm
Package width: 245 mm
Quantity per pack: 1 pc(s)
Package type: Box
Package height: 75 mm
Ports & interfaces
3.5 mm (1/8inch) out: Yes
RS232 output ports: 1
Remote (IR) output: 2
RJ45 input ports: 1
USB ports quantity: 2
Serial interface type: RS232
3.5 mm (1/8inch) in: Yes
HDMI in: 1
RS232 input ports: 1
Serial ports quantity: 2
USB connector type: MicroUSB
Remote (IR) input: 2
RJ45 output ports: 1
Number of HDMI outputs: 1
DCin jack: Yes
Connectivity technology: Wired
Logistics data
UK Trade Tariff code: 85176200
