Design
Cooling type: Active
On/off switch: Yes
Fan diameter: 12 cm
Fan location: Top
Product colour: Black
Number of fans: 1 fan(s)
Power
AC input frequency: 50/60 Hz
Total power: 1000 W
Combined power (+3.3V): 120 W
Power protection features: Under voltage, Over current, Over voltage, Surge & inrush protection (SIP), Over power, Overheating, Surge protection, No load operation
AC input voltage: 100 240 V
Efficiency: 90%
Max output current (+12V): 83.3 A
Combined power (12V): 3.6 W
Max output current (12V): 0.3 A
Max output current (+5Vsb): 3 A
Power Good signal delay range: 100 150 ms
Max output current (+5V): 22 A
Power Factor Correction (PFC) type: Active
Max output current (+3.3V): 22 A
Combined power (+5V): 120 W
Hold time: 16 ms
Combined power (+12V): 999.6 W
Operational conditions
Operating temperature (TT): 0 40 C
Weight & dimensions
Height: 85 mm
Width: 150 mm
Depth: 150 mm
Performance
ATX version: 3.1
Purpose: PC
80 PLUS certification: 80 PLUS Gold
Bearing technology: FDB
Power supply unit (PSU) form factor: ATX
Mean time between failures (MTBF): 100000 h
Packaging data
Package type: Box
Certification: CE/FCC/CCC/RCM/EAC/CAN ICES003(B)/NMB003(B) /TUVRH
Certificates
Compliance certificates: WEEE, RoHS
Ports & interfaces
Cabling type: Modular
Motherboard power connector: 24pin ATX
Motherboard power cable length: 54 cm
