Technical details
Sustainability certificates: ErP, Triman
Design
Product colour: Black
Fan diameter: 9.2 cm
Cooling type: Active
Number of fans: 1 fan(s)
Power
Power protection features: Overheating, Short circuit, Over voltage, Surge & inrush protection (SIP), No load operation, Over power, Under voltage, Over current
AC input frequency: 50/60 Hz
Combined power (+3.3V): 100 W
Input current: 10 5 A
AC input voltage: 100 240 V
Total power: 750 W
Efficiency: 90%
Max output current (+3.3V): 20 A
Hold time: 16 ms
Combined power (+5Vsb): 15 W
Combined power (12V): 3.6 W
Combined power (+12V): 750 W
Max output current (+5Vsb): 3 A
Max output current (12V): 0.3 A
Combined power (+5V): 100 W
Max output current (+5V): 20 A
Power Factor Correction (PFC) type: Active
Max output current (+12V): 62.5 A
Operational conditions
Operating temperature (TT): 0 40 C
Weight & dimensions
Width: 125 mm
Height: 63.5 mm
Depth: 100 mm
Performance
Bearing technology: FDB
Mean time between failures (MTBF): 100000 h
ATX version: 3.1
Purpose: PC
Power supply unit (PSU) form factor: SFX
Packaging data
Manual: Yes
Package type: Box
Packaging content
Cables included: CPU, PCIe, Peripheral (Molex), SATA, AC
Cable tie(s) included: Yes
Certification: Cybenetics Platinum/PPLP Gold ATX3.1
Certificates
Compliance certificates: KC, CCC, TV mark, RoHS, CE, RCM, ICES, EAC
Ports & interfaces
Cabling type: FullyModular
PCI Express power connectors (6+2 pin): 3
Peripheral (Molex) power connectors (4pin): 1
PCI Express connector: Yes
PCI Express power connectors (16pin): 1
Motherboard power cable length: 35 cm
SATA power cable length: 300, 120
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 3
PCI Express power cable length: 45 cm
CPU power cable length: 50 cm
Peripheral (Molex) power cable length: 120
Logistics data
Warranty period: 5 year(s)
