Opis i karakteristike
Technical details
Sustainability certificates: CE, RoHS
Compliance certificates: RoHS, CE
Features
Power protection features: Over current, Short circuit, Overload, Input fuse
Output power capacity: 3 kVA
Input frequency: 50/60 Hz
Maximum current: 13.04 A
Power factor: 0.9
Output power: 2700 W
Crest factor: 3:1
Surge protection: Yes
Output operation voltage (min): 208 V
Surge energy rating: 370 J
Emergency Power Off (EPO): Yes
Output voltage Total Harmonic Distortion (THD): 5%
Input operation voltage (min): 190 V
Input power factor: 0.98
Waveform: Pure sine
EMI/RFI noise filtering: Yes
UPS topology: Doubleconversion (Online)
Output operation voltage (max): 240 V
Input operation voltage (max): 300 V
Output frequency: 50/60 Hz
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Number of input phases: 1
Efficiency (ECO mode): 95%
Audible alarm(s): Yes
Design
Cable length: 1.5 m
Housing material: Metal
Product colour: Black
Form factor: Tower
Display type: LCD
Operational conditions
Operating temperature (TT): 0 40 C
Nonoperating altitude: 0 1500 m
Operating altitude: 0 1500 m
Operating relative humidity (HH): 20 90%
Storage relative humidity (HH): 10 90%
Storage temperature (TT): 20 50 C
Weight & dimensions
Height: 337 mm
Weight: 26 kg
Depth: 416 mm
Package height: 458 mm
Width: 169 mm
Package width: 295 mm
Ports & interfaces
USB port: Yes
AC outlet types: C19 coupler, Terminal, C13 coupler
Emergency Power Off (EPO) connector: Yes
Power plug: C20 coupler
AC outlets quantity: 8 AC outlet(s)
Battery
Number of batteries supported: 3
Typical backup time at full load: 4.3 min
Replacement battery cartridge: BPSE72V40A
Typical backup time at half load: 13.1 min
Charging current: 1.5 A
Battery recharge time: 4 h
Battery technology: Sealed Lead Acid (VRLA)
Logistics data
Harmonized System (HS) code: 8504408590
