Technical details
Sustainability certificates: RoHS
Features
Output operation voltage (min): 230 V
Output power capacity: 1 kVA
UPS topology: LineInteractive
Output operation voltage (max): 230 V
Output power: 600 W
Power factor: 0.6
Power protection features: Overload
Automatic Voltage Regulation (AVR): Yes
Input operation voltage (min): 165 V
EMI/RFI noise filtering: Yes
Response time: 4 ms
Output frequency: 50/60 Hz
Surge protection: Yes
Waveform: Sine
Audible alarm(s): Yes
Audible alarm modes: Fault, Low battery alarm, Overload alarm
Input frequency: 50/60 Hz
Surge energy rating: 810 J
Input operation voltage (max): 271 V
Maximum current: 10 A
Certification: CE, EAC, RCM
Design
Product colour: Silver
LED indicators: Operation
Form factor: Rackmount
Housing material: Metal
Rack capacity: 1U
Cable length: 1.83 m
Display type: LCD
Operational conditions
Storage temperature (TT): 15 45 C
Operating temperature (TT): 0 40 C
Storage relative humidity (HH): 0 95%
Operating altitude: 0 3000 m
Operating relative humidity (HH): 0 95%
Nonoperating altitude: 0 15000 m
Weight & dimensions
Depth: 389 mm
Package height: 158 mm
Width: 433 mm
Weight: 13.7 kg
Height: 44 mm
Package width: 545 mm
Packaging data
Cables included: USB cable
Ports & interfaces
AC outlet types: C13 coupler
Modem (RJ11) ports: 1
AC outlets quantity: 6 AC outlet(s)
Ethernet LAN (RJ45) ports: 1
USB port: Yes
Power plug: C14 coupler
Serial ports quantity: 1
Battery
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at half load: 14 min
Hotswap battery: Yes
Typical backup time at full load: 3.5 min
Number of batteries supported: 1
Battery recharge time: 8 h
Logistics data
Harmonized System (HS) code: 8504408590
