Opis i karakteristike
Design
Product colour: Black
LED indicators: Link, Activity, System, Power
Power
Power supply included: Yes
AC input voltage: 100 240 V
Power source: AC
Security
Authentication: Portbased authentication
DHCP features: DHCP server, DHCP snooping, DHCP relay
IGMP snooping: Yes
SSH/SSL support: Yes
IPMACPort binding: Yes
Authentication type: AAA, RADIUS, TACACS+
Operational conditions
Storage temperature (TT): 40 70 C
Operating relative humidity (HH): 10 90%
Operating temperature (TT): 10 50 C
Storage relative humidity (HH): 5 90%
Management features
Quality of Service (QoS) support: Yes
System event log: Yes
Switch layer: L3
Switch type: Managed
Webbased management: Yes
Weight & dimensions
Weight: 3.87 kg
Depth: 280 mm
Height: 44 mm
Width: 440 mm
Network
Number of VLANs: 4096
10G support: Yes
Port mirroring: Yes
MAC address autolearning supported: Yes
Flow control support: Yes
Broadcast storm control: Yes
Link aggregation: Yes
VLAN support: Yes
Cable types supported: Cat3, Cat4, Cat5
MAC address autoaging supported: Yes
Spanning tree protocol: Yes
Rate limiting: Yes
Ethernet LAN data rates: 10,1000,100 Mbit/s
Networking standards: IEEE 802.3az, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3i, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae
IP routing: Yes
Virtual LAN features: Voice VLAN
Performance
Flash memory: 32 MB
Internal memory: 512 MB
Memory type: DDRSDRAM
Packaging data
Package height: 85 mm
Package width: 500 mm
Package depth: 365 mm
Package type: Box
Package weight: 4.7 kg
Protocols
IPv4 & IPv6 features: IPv6 ping, IPv6 Telnet, IPv6 tracert
Routing protocols: OSPF
Ports & interfaces
Console port: RJ45/USB TypeA
Installed SFP+ modules quantity: 4
USB TypeA ports quantity: 1
Gigabit Ethernet (copper) ports quantity: 48
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 48
Data transmission
Packet buffer memory: 2 MB
Static route: Yes
Forwarding rate: 131 Mpps
MAC address table: 32000 entries
Switching capacity: 176 Gbit/s
Jumbo frames support: Yes
Jumbo frames: 12
Multicast features
Multicast support: Yes
Safety warning
Warnings: The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself.
Optical fiber
Fiber type: Multimode
