Opis i karakteristike
Technical details
Sustainability certificates: ErP
Design
Cooling type: Active
Product colour: White
Fan diameter: 14 cm
Fan location: Top
On/off switch: Yes
Power
Max output current (+3.3V): 20 A
Power protection features: Overcharge, Under voltage, Short circuit, Over voltage, Over total voltage, Over power
Efficiency: 90%
Combined power (+5V): 120 W
Max output current (+5Vsb): 3 A
Power Good signal delay range: 100 150 ms
Hold time: 16 ms
Max output current (12V): 0.3 A
Power Factor Correction (PFC) type: Active
Total power: 1050 W
Combined power (12V): 3.6 W
Max output current (+12V): 87.5 A
AC input frequency: 50/60 Hz
Combined power (+3.3V): 120 W
Combined power (+12V): 105 W
Input current: 13 6 A
AC input voltage: 100 240 V
Max output current (+5V): 20 A
Combined power (+5Vsb): 15 W
Weight & dimensions
Width: 150 mm
Depth: 180 mm
Height: 86 mm
Weight: 2.93 kg
Performance
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Bearing technology: FDB
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Packaging data
Package height: 122 mm
Case or master carton dimensions (W x D x H): 325 x 620 x 220 mm
Package type: Box
Package depth: 333 mm
Package weight: 3.36 kg
Package width: 197 mm
Certificates
Compliance certificates: UKCA, Federal Communications Commission (FCC), EAC, cTUVus, CE, BSMI, CCC, RCM, BIS, TV mark
Ports & interfaces
SATA power cable length: 740, 500, 620, 860 mm
Motherboard power cable length: 65 cm
Peripheral (Molex) power cable length: 860 mm, 500, 740, 620
Peripheral (Molex) power connectors (4pin): 4
Number of SATA power connectors: 12
PCI Express power connectors (6+2 pin): 3
Motherboard power connector: 24pin ATX
ATX Power connector (24pin): Yes
EPS power connector (8pin): Yes
EPS power connector (4+4 pin): Yes
Cabling type: FullyModular
PCI Express power connectors (12pin): 1
