Asus 1700 AS STRIX B760-F GAMING WIFI cijene

Processor
Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel Core i7, Intel Core i9, Intel Pentium Gold, Intel Core i3, Intel Core i5, Intel Celeron
Processor socket: LGA 1700
Maximum number of SMP processors: 1

Graphics
Parallel processing technology support: Not supported
Onboard graphics card: No

Features
Product colour: Black
Motherboard chipset family: Intel
Windows operating systems supported: Windows 10, Windows 11
Power source type: ATX
Audio output channels: 7.1 channels
Motherboard chipset: Intel B760
Cooling type: Passive
Motherboard form factor: ATX
Audio chip: Realtek ALC4080

Memory
Supported memory clock speeds: 6600, 7000, 6800, 6200, 6400, 5000, 5800, 5400, 4800 MHz, 5600, 7800 MHz, 6000, 5200
Unbuffered memory: Yes
Number of memory slots: 4
Memory channels: Dualchannel
Supported memory clock speed (max): 7800 MHz
Memory slots type: DIMM
Supported memory types: DDR5SDRAM
Maximum internal memory: 192 GB
ECC ompatibility: NonECC

Weight & dimensions
Depth: 244 mm
Width: 305 mm

Network
WiFi standards: 802.11g, 802.11a, WiFi 6 (802.11ax), WiFi 6E (802.11ax), WiFi 5 (802.11ac), 802.11b, WiFi 4 (802.11n)
WiFi: Yes
Top WiFi standard: WiFi 6E (802.11ax)
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth: Yes
Bluetooth version: 5.3

Internal I/O
Peripheral (Molex) power connectors (4pin): 1
EPS power connector (8pin): Yes
USB 2.0 connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of chassis fan connectors: 4
ATX Power connector (24pin): Yes
Chassis intrusion connector: Yes
RGB LED pin header: Yes
CPU fan connector: Yes
Thunderbolt headers: 1
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel connector: Yes
Front panel audio connector: Yes
12V power connector: Yes

BIOS
Clear CMOS button: Yes
BIOS type: UEFI AMI

Packaging data
Package width: 280 mm
Package height: 265 mm
Package weight: 1.27 kg
Package depth: 71 mm

Packaging content
User guide: Yes
Cables included: SATA

Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID levels: 10, 5, 0, 1
Number of storage drives supported: 7
Number of HDDs supported: 4
RAID support: Yes
Supported storage drive types: HDD & SSD

Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 6
DisplayPort version: 1.4
HDMI ports quantity: 1
USB 3.2 Gen 2x2 TypeC ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 1
HDMI version: 2.1
DisplayPorts quantity: 1
Headphone outputs: 1
S/PDIF out port: Yes
WiFiAP antenna jack: 2
Microphone in: Yes
Linein: Yes
Ethernet LAN (RJ45) ports: 1

Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 1

Other features
BacktoBIOS button: Yes

Safety warning
Warnings: Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
