Design
Housing material: Metal
Rack mounting: No
Stackable: No
Product colour: Grey
LED indicators: Yes
Power
Power consumption (max): 75 W
Power supply included: Yes
DC input voltage: 53.5 V
Number of power supply units: 1
Power source: DC/PoE
Input current: 1.31 A
AC input voltage: 100 240 V
AC input frequency: 50/60 Hz
Security
IGMP snooping: Yes
Operational conditions
Storage relative humidity (HH): 5 90%
Heat dissipation: 225.75 BTU/h
Operating relative humidity (HH): 10 90%
Storage temperature (TT): 40 70 C
Operating temperature (TT): 0 40 C
Management features
Switch type: Managed
Quality of Service (QoS) support: No
Weight & dimensions
Width: 171 mm
Depth: 98 mm
Height: 27 mm
Network
Cable types supported: Cat3, Cat4, Cat5, Cat5e
Flow control support: Yes
MAC address autoaging supported: Yes
10G support: No
Copper ethernet cabling technology: 100BASETX, 1000BASET, 10BASET
Auto MDI/MDIX: Yes
MAC address autolearning supported: Yes
Autonegotiation: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3af, IEEE 802.3x, IEEE 802.3i
Performance
Fanless: Yes
Maximum cable length: 100 m
Packaging data
Package height: 68 mm
Package depth: 280 mm
Cables included: AC
Package width: 223 mm
User guide: Yes
Package weight: 900 g
Package type: Box
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 8
Power connector: DCin jack
Basic switching RJ45 Ethernet ports quantity: 8
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Jumbo frames support: Yes
Jumbo frames: 16000
MAC address table: 4000 entries
Switching capacity: 16 Gbit/s
Storeandforward: Yes
Forwarding rate: 11.904 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Total Power over Ethernet (PoE) budget: 64 W
Power over Ethernet (PoE): Yes
Sustainability
Sustainability certificates: Federal Communications Commission (FCC), CE, RoHS
Sustainability compliance: Yes
