Opis i karakteristike
Technical details OpenCL version: 3.0 Status: Launched Launch date: Q1'24 Processor Performancecore base frequency: 3.5 GHz Performance cores: 4 Performancecore boost frequency: 4.7 GHz Maximum number of DMI lanes: 8 Processor base power: 60 W Processor generation: Intel Core i3 (14th gen) Maximum turbo power: 110 W Package type: Box Processor codename: Raptor Lake Processor boost frequency: 4.7 GHz Processor manufacturer: Intel Processor socket: LGA 1700 Processor ARK ID: 236774 Processor cache: 12 MB Processor family: Intel Core i3 Processor model: i314100 Processor cores: 4 Processor threads: 8 Stepping: H0 Memory bandwidth supported by processor (max): 76.8 GB/s Processor cache type: Smart Cache Processor operating modes: 64bit Cooler included: Yes Graphics MultiFormat Codec Engines: 1 Onboard graphics card model: Intel UHD Graphics 730 Onboard graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, HDMI 2.1, DisplayPort 1.4a Discrete graphics card model: Not available Onboard graphics card DirectX version: 12.0 Number of execution units: 24 Onboard graphics card: Yes Number of displays supported (onboard graphics): 4 Onboard graphics card ID: 0x4692 Onboard graphics card dynamic frequency (max): 1500 MHz Discrete graphics card: No Onboard graphics card OpenGL version: 4.5 Onboard graphics card maximum resolution (eDP Integrated Flat Panel): 5120 x 3200 pixels Onboard graphics card refresh rate at maximum resolution (eDP Integrated Flat Panel): 120 Hz Onboard graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels Onboard graphics card maximum resolution (HDMI): 4096 x 2160 pixels Onboard graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz Onboard graphics card refresh rate at maximum resolution (HDMI): 60 Hz Features Export Control Classification Number (ECCN): 5A992C Commodity Classification Automated Tracking System (CCATS): 740.17B1 Direct Media Interface (DMI) Revision: 4.0 Use conditions: PC/Client/Tablet CPU configuration (max): 1 Thermal Monitoring Technologies: Yes PCI Express configurations: 1x16+1x4, 2x8+1x4 Embedded options available: Yes Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2 PCI Express slots version: 5.0, 4.0 Execute Disable Bit: Yes Idle States: Yes Scalability: 1S Market segment: Desktop Maximum number of PCI Express lanes: 20 Memory Memory channels: Dualchannel Memory bandwidth (max): 76.8 GB/s Memory types supported by processor: DDR5SDRAM, DDR4SDRAM Maximum internal memory supported by processor: 192 GB Operational conditions Tjunction: 100 C Weight & dimensions Processor package size: 45 x 37.5 mm Processor special features Intel Controlflow Enforcement Technology (CET): Yes Intel Gaussian & Neural Accelerator (Intel GNA) 3.0: Yes Intel Standard Manageability (ISM): Yes Intel Hyper Threading Technology (Intel HT Technology): Yes Intel Clear Video HD Technology (Intel CVT HD): Yes Intel AES New Instructions (Intel AESNI): Yes Intel OS Guard: Yes Intel Quick Sync Video Technology: Yes Intel Turbo Boost Technology: 2.0 Enhanced Intel SpeedStep Technology: Yes Intel Virtualization Technology for Directed I/O (VTd): Yes Intel Virtualization Technology (VTx): Yes Intel Secure Key: Yes Intel 64: Yes Intel VTx with Extended Page Tables (EPT): Yes Modebased Execute Control (MBE): Yes Intel Boot Guard: Yes Intel Deep Learning Boost (Intel DL Boost) on CPU: Yes Intel Volume Management Device (VMD): Yes Intel Speed Shift Technology: Yes Other features Maximum internal memory: 192 GB L2 cache: 5120 KB Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1 Logistics data Harmonized System (HS) code: 8542310001
Pročitaj više
Prijavi pogrešku
Tip procesora
Intel Core i3
Proizvođač procesora
Intel
Porodica procesora
Intel® Core™ i3
Utor za procesor
LGA 1700
Memorijska propusnost (maksimalna) (GB/s)
76.8
Procesorske niti (threads)
8
Memorijski kanali
Dvokanalni
Načini rada procesora
64-bit
Procesorska pojačana frekvencija (GHz)
4.7
Predmemorija procesora (MB)
12
Kodno ime procesora
Raptor Lake
Najveća interna memorija podržana procesorom (GB)
192
Tipovi memorije podržane procesorom
DDR5-SDRAM, DDR4-SDRAM
Najveća brzina memorije podržana procesorom (GB/s)
76.8
Maksimalan broj DMI staza
8
Nazivna snaga procesora (W)
60
Maksimalna turbo snaga (W)
110
Osnovna frekvencija P-jezgre (GHz)
3.5
Boost frekvencija P-jezgre (GHz)
4.7
Generacija procesora
Intel Core i3-14xxx
Prikaži sve
(21)
Šifra harmoniziranog sustava (HS)
8542310001
Maksimalna količina interne memorije (GB)
192
L2 priručna memorija (KB)
5120
Grafički izlaz
eDP 1.4b, DP 1.4a, HDMI 2.1
Model ugrađenog grafičkog prilagodnika
Intel UHD Graphics 730
Model odvojenog grafičkog prilagodnika
Nije dostupno
Adapter za grafičku karticu na ploči
Dinamička frekvencija (maks) ugrađenog grafičkog prilagodnika (MHz)
1500
Podržani izlazni priključci ugrađenog grafičkog prilagodnika
DisplayPort 1.4a, HDMI 2.1, Embedded DisplayPort (eDP) 1.4b
Najveća rezolucija ugrađenog grafičkog prilagodnika (DisplayPort) (piksela)
7680 x 4320 pikseli
Broj izvršnih jedinica
24
ID grafičkog adaptera na ploči
0x4692
Maksimalna razlučivost ugrađenog grafičkog prilagodnika (eDP - Integrated Flat Panel) (piksela)
5120 x 3200 pikseli
Brzina osvježavanja na maksimalnoj razlučivosti ugrađenog grafičkog prilagodnika (eDP-integrirana)) (Hz)
120
Brzina osvježavanja na maksimalnoj razlučivosti ugrađenog grafičkog prilagodnika (DisplayPort) (Hz)
60
Brzina osvježavanja na maksimalnoj razlučivosti ugrađenog grafičkog prilagodnika (HDMI) (Hz)
60
Broj podržanih zaslona (ugrađena grafika)
4
Maksimalna razlučivost ugrađenog grafičkog prilagodnika (HDMI) (piksela)
4096 x 2160 pikseli
DirectX verzija ugrađenog grafičkog prilagodnika
12.0
OpenGL verzija ugrađenog grafičkog prilagodnika
4.5
Diskretni grafički adaptor
Moduli kodeka s više formata
1
Prikaži sve
(11)
Veličina pakiranja procesora (mm)
45 x 37.5 mm
Posebne značajke procesora
Intel Hyper-Threading Technology
Intel Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Intel Clear Video HD Technology
Intel AES New Instructions
Unaprijeđena Intel SpeedStep tehnologija
Intel VT-x with Extended Page Tables (EPT)
Podrška za Intel Virtualization Technology for Directed I/O (VT-d)
Tehnologija Intel Virtualization (VT-x)
Intel® Speed Shift Tehnologija
Upravljanje utemeljeno na načinu rada (MBE)
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Intel® Volume Management Device (VMD)
Intel® Control-flow Enforcement tehnologija (CET)
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Intel® Standard Manageability (ISM)
Prikaži sve
(13)
Verzija PCI Express utora
4.0, 5.0
Tehnologija temperaturnog monitoringa
Konfiguracija procesora (maks)
1
Konfiguracija PCI Express utora
1x16+1x4, 2x8+1x4
Najveći broj PCI Express stazica
20
Tržišni segment
Stolno računalo
Klasifikacijski broj za kontrolu izvoza (ECCN)
5A992C
Sustav automatskog praćenja klasifikacije robe (CCATS)
740.17B1
Uvjeti uporabe
PC/Client/Tablet
Direct Media Interface (DMI) revizija
4.0
Prikaži sve
(8)
