Design Screen shape: Flat Panel mounting interface: 400 x 400 mm Product design: Digital signage flat panel Product colour: Black Placement supported: Indoor VESA mounting: Yes Bezel width (side): 3 cm Orientation: Horizontal/Vertical Bezel width (bottom): 3 cm Antiglare screen: Yes Bezel width (top): 3 cm Power AC input frequency: 50/60 Hz Power consumption (off): 0.3 W AC input voltage: 100 240 V Power consumption (typical): 139 W Power consumption (standby): 0.5 W Energy efficiency class (SD
Design Screen shape: Flat Panel mounting interface: 400 x 400 mm Product design: Digital signage flat panel Product colour: Black Placement supported: Indoor VESA mounting: Yes Bezel width (side): 3 cm Orientation: Horizontal/Vertical Bezel width (bottom): 3 cm Antiglare screen: Yes Bezel width (top): 3 cm
Power AC input frequency: 50/60 Hz Power consumption (off): 0.3 W AC input voltage: 100 240 V Power consumption (typical): 139 W Power consumption (standby): 0.5 W Energy efficiency class (SDR): F Energy consumption (SDR) per 1000 hours: 78 kWh Energy efficiency scale: A to G
Operational conditions Operating temperature (TT): 0 40 C Storage temperature (TT): 20 60 C
Weight & dimensions Height (with stand): 744.8 mm Width (with stand): 1274 mm Depth (with stand): 65.2 mm Display width: 1274 mm Display depth: 65.2 mm Weight (with stand): 39.6 kg Display height: 744.8 mm Display weight: 39.6 kg
Performance On Screen Display (OSD) languages: Spanish, German, English, Polish, Russian, Italian, Dutch, Finnish, French, Danish, Slovenian, Czech On Screen Display (OSD): Yes Purpose: Universal International Protection (IP) code: IP65 HDCP: Yes Number of OSD languages: 13 HDCP version: 2.2 Mean time between failures (MTBF): 50000 h Operating hours (hours/days): 24/7
Packaging data Package weight: 47.2 kg Package height: 894 mm Package width: 1428 mm Package depth: 1428 mm Package volume: 47200 cm
Display Touchscreen: Yes Pixel pitch: 0.315 x 0.315 mm Response time: 8 ms Display resolution: 3840 x 2160 pixels Viewing angle, horizontal: 178 Display diagonal: 138.7 cm (54.6") Panel type: IPS Native aspect ratio: 16:9 HD type: 4K Ultra HD Contrast ratio (typical): 1200:1 Display diagonal (metric): 139 cm Viewing angle, vertical: 178 Horizontal scan range: 28 160 kHz Display technology: LED Display number of colours: 1.07 billion colours LED backlight: Yes Multitouch: Yes Display brightness: 500 cd/m Number of simultaneous touchpoints: 40 Haze rate: 25% Surface hardness: 7H Native refresh rate: 60 Hz Active display area (W x H): 1209.6 x 680.4 mm Glass thickness: 4 mm Touchscreen technology: Projected capacitive system
Audio Builtin speaker(s): Yes RMS rated power: 20 W Number of builtin speakers: 2
Ports & interfaces USB port: Yes HDMI ports quantity: 2 USB connector type: USB TypeB, USB TypeA Ethernet LAN: Yes HDMI version: 2.0 DisplayPorts quantity: 1 DisplayPort version: 1.2 DVI port: No Ethernet LAN (RJ45) ports: 1 RS232C: Yes USB 2.0 TypeB ports quantity: 1 USB ports quantity: 3
Other features Display surface: Matt Quick start guide: Yes Power supply type: Internal Viewable size, horizontal: 121 cm Viewable size, vertical: 68 cm Maximum refresh rate: 60 Hz
Computer system Processor manufacturer: ARM Builtin processor: Yes Internal memory: 4 GB Operating system installed: Android Processor architecture: ARM CortexA53+CortexA73 Operating system version: 11 Internal storage capacity: 32 GB Computer system: Yes
