Opis i karakteristike
Certification: IEC 62196, IEC 62752, IEC 60309, EN 300 2201/2, EN 300 328, EN 301 4891/17, EN 301 4891/3, EN 301 4891/52, EN 301 511
Features
Direct current failure monitoring: Yes
Vehicle charging standard: Mode 3
Vehicle connection plug: Type 2
Mechanical impact protection code: IK10
Quantity per pack: 1 pc(s)
Firmware upgradeable: Yes
Near Field Communication (NFC): Yes
WiFi: Yes
International Protection (IP) code: IP54
RFID reader: Yes
Over current protection: Yes
Design
Housing material: Aluminium
Product colour: Grey
Integrated charging cable: Yes
Cable colour: Black
Mounting type: Wall
Builtin display: Yes
Display technology: LED
Power
Singlephase output voltage supported: 230 V
Maximum charging power: 22000 W
Threephase output voltage supported: 400 V
Minimum operating power (singlephase): 1.4 kW
Maximum operating current (threephase): 32 A
Power source type: AC
Maximum operating current per phase: 32 A
Maximum operating power (threephase): 22 kW
Maximum operating power (singlephase): 7.2 kW
Number of phases: 3
Weight & dimensions
Depth: 73 mm
Height: 338 mm
Weight: 5.51 kg
Charging cable length: 5 m
Width: 211 mm
