Design Fan diameter: 12 cm On/off switch: Yes Number of fans: 1 fan(s) Product colour: Black Power Total power: 550 W AC input frequency: 50 60 Hz AC input voltage: 100 240 V Power protection features: UVP (undervoltage protection), OVP (overvoltage protection), NLO, SCP (short circuit protection), OTP (overheat protection), OCP (overcurrent protection), OPP (overload protection), SIP (surge and shock protection) Operational conditions Operating temperature (TT): 0 40 C Weight & dimensions Dept
Design Fan diameter: 12 cm On/off switch: Yes Number of fans: 1 fan(s) Product colour: Black
Power Total power: 550 W AC input frequency: 50 60 Hz AC input voltage: 100 240 V Power protection features: UVP (undervoltage protection), OVP (overvoltage protection), NLO, SCP (short circuit protection), OTP (overheat protection), OCP (overcurrent protection), OPP (overload protection), SIP (surge and shock protection)
Operational conditions Operating temperature (TT): 0 40 C
Weight & dimensions Depth: 140 mm Width: 150 mm Height: 86 mm
Performance Cooling type: Active 80 PLUS certification: 80 PLUS Bronze Mean time between failures (MTBF): 100000 h ATX version: 3.0 Efficiency: 85 %
Packaging data Package type: Box
Packaging content Cables included: AC
Ports & interfaces Number of SATA power connectors: 6 Cabling type: NonModular PCI Express power connectors (6+2 pin): 3 Motherboard power connector: 20+4 pin ATX ATX power connector (20+4 pin): Yes CPU power connectors 4+4 (8pin) : 2 Power supply connectors: EPS12V Number of power connectors 12VHPWR (12V 2x6 pin): 1
Safety warning Warnings: The product is not suitable for disposal with municipal waste dispose of in accordance with local regulations., Do not open the case risk of electric shock.
Prijavi pogrešku
Karakteristike
Ulazna struja (A)
8 - 4 A
Tip ambalaže
Kutija
Vrijeme držanja (ms)
16
Poveznik napajanja matične ploče
20+4 pin ATX
Broj SATA poveznika napajanja
6
Poveznik napajanja procesora (4+4 nožice)
PCI Express poveznik napajanja (6+2 nožice)
3
Aktivno
Kombinirana snaga (+3,3V) (W)
100
Kombinirana snaga (+12V) (W)
549.6
Kombinirana snaga (+5V) (W)
100
Kombinirana snaga (-12V) (W)
3.6
Kombinirana snaga (+5Vsb) (W)
15
Max output current (+3.3V) (A)
20
Max output current (+12V) (A)
45.8
Max output current (+5V) (A)
20
Max output current (-12V) (A)
0.3
Max output current (+5Vsb) (A)
3
Vrsta kabliranja
Ne modularno
Duljina kabela napajanja matične ploče (mm)
550
Duljina kabela SATA napajanja (mm)
450,550,650 mm
Raspon vremena kašnjenja signala ispravnog napajanja (ms)
