Design
Product colour: Black
Cooling type: Active
On/off switch: Yes
Fan location: Top
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Power
Power Factor Correction (PFC) type: Active
Power protection features: Under voltage, Over current, Overheating, Surge protection, No load operation, Over voltage, Over power, Surge & inrush protection (SIP)
Combined power (+3.3V): 110 W
AC input voltage: 100 240 V
Max output current (+3.3V): 20 A
Combined power (12V): 3.6 W
Total power: 650 W
Max output current (12V): 0.3 A
AC input frequency: 50/60 Hz
Efficiency: 85%
Combined power (+5V): 110 W
Power Good signal delay range: 100 150 ms
Max output current (+12V): 54 A
Combined power (+12V): 648 W
Hold time: 16 ms
Max output current (+5V): 20 A
Operational conditions
Operating temperature (TT): 0 40 C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 140 mm
Performance
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Bearing technology: HDB
Power supply unit (PSU) form factor: ATX
Purpose: PC
Packaging data
Package type: Box
Certification: CE/FCC/CCC/RCM/EAC/CAN ICES003(B)/NMB003(B) /TUVRH
Certificates
Compliance certificates: RoHS, WEEE
Ports & interfaces
Motherboard power connector: 24pin ATX
Motherboard power cable length: 50 cm
Cabling type: NonModular
