Dahua Technology Consumer DH-IPC-HDBW1230DEP-SW-0280B security camera Dome IP security camera Outdoor 1920 x 1080 pixels Ceiling cijene
Design IK code: IK10 International Protection (IP) code: IP67 Housing material: Metal Form factor: Dome Mounting type: Ceiling Product colour: White Power Power consumption (max): 4.9 W Power consumption (typical): 2 W DC output voltage: 12 Power source type: DC Security HTTPS encryption: Yes Video motion detection: Yes Motion sensor: Yes Security algorithms: HTTPS Operational conditions Operating relative humidity (HH): 0 95% Operating temperature (TT): 40 60 C Storage temperature (TT): 30 60
Je li ti ovaj odjeljak koristan?
Ostavi svoj dojam klikom na emotikon i ispuni anketu.
Prikazan je tvoj odabrani proizvod te artikli koje kupci najčešće biraju u kategoriji IP kamere za video nadzor. Graf prikazuje kako se potražnja mijenja kroz različite cjenovne razrede. Prilagodi prikaz TOP 10 proizvoda svom budžetu odabirom cjenovnog razreda — Jeftiniji / Osnovni / Premium — ili odabirom brenda.
Je li ti ovaj odjeljak koristan?
Opis i karakteristike
Design IK code: IK10 International Protection (IP) code: IP67 Housing material: Metal Form factor: Dome Mounting type: Ceiling Product colour: White
Power Power consumption (max): 4.9 W Power consumption (typical): 2 W DC output voltage: 12 Power source type: DC
Weight & dimensions Height: 88.7 mm Diameter: 11.1 cm Weight: 414 g
Network WiFi standards: 802.11g, 802.11b, WiFi 4 (802.11n) Supported network protocols: IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP Ethernet LAN: Yes Ethernet interface type: Fast Ethernet WiFi: Yes Channel bandwidth: 36 MHz Live view: Yes Number of users: 6 user(s) Bluetooth: No WiFi data rate (max): 2400 Mbit/s
System requirements Mobile operating systems supported: iOS, Android
Performance Antennas quantity: 1 Wide Dynamic Range (WDR): Yes Placement supported: Outdoor Dynamic range: 56 dB Luminous flux: 0.0025 lm Type: IP security camera Antenna type: External Connectivity technology: Wired & Wireless
Packaging data Package weight: 592 g
Packaging content Number of cameras: 1
Audio SignaltoNoise Ratio (SNR): 56 dB
Storage Card reader integrated: Yes Flash memory: 64 MB Maximum memory card size: 256 GB Compatible memory cards: MicroSD (TransFlash) Builtin HDD: No ROM capacity: 16 MB
Ports & interfaces Ethernet LAN (RJ45) ports: 1
Camera Minimum illumination: 0.0025 lx White balance: Manual, Street lamp, Custom modes, Outdoor, Natural Camera shutter speed: 1/3 s1/100,000 s Angle of rotation: 355 Camera shutter type: Electronic Adjustment shutter speed: Auto/Manual Camera tilt control: Yes Pan range: 0 355 Camera pan control: Yes Field of view (FOV) angle: 120 Tilt angle range: 0 75 Lens viewing angle, diagonal: 120 Lens viewing angle, horizontal: 100 Lens viewing angle, vertical: 53
Image sensor Progressive scan: Yes Optical sensor size: 25.4 / 2.8 mm (1 / 2.8") Number of sensors: 1 Sensor type: CMOS
Video Back Light Compensation (BLC): Yes Frame rate: 30 fps Total megapixels: 2 MP Smart IR: Yes Region of Interest (ROI) encoding: Yes Flip & mirror: Yes Supported video modes: 720p, 1080p, 960p Bit rate: 9 4096 Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Noise reduction: Yes Noise reduction technology: 3D noise reduction Video formats supported: H.264, H.265, H.264B Video streaming: Yes Privacy masking: Yes Digital Wide Dynamic Range (DWDR): Yes Video compression formats: H.264H, H.264B, H.265, H.264 Video recording: Yes Gain control type: Auto Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1280 x 960 Maximum resolution: 1920 x 1080 pixels
Night vision LED type: IR Night vision: Yes Number of illumination LEDs: 3
Lens system Recognize distance: 9.4 m Zoom capability: No Fixed focus: Yes Observe distance: 18.8 m Focal length range: 2.8 mm Detect distance: 46.9 m Maximum aperture number: 2 Number of lenses: 1 Identify distance: 4.7 m Lens diameter: 2.8 mm
Sustainability Compliance certificates: CE, Federal Communications Commission (FCC)
Prijavi pogrešku
Učinak
Tip
IP sigurnosna kamera
Opseg relativne vlažnosti pri radu (H-H) (%)
0 - 95%
Raspon radne temperature (T-T) (°C)
-40 - 60 °C
Tip antene
Eksterno
Minimalno osvjetljenje (lx)
0.0025
Maksimalna razlučivost (piksela)
1920 x 1080 pikseli
Formati video kompresije
H.264B, H.265, H.264, H.264H
Kut rotacije (°)
355
Redukcija buke
Dinamički raspon (dB)
56
Podržane opcije postavljanja
Vanjski
Broj kadrova u sekundi (fps)
30
Podržane grafičke rezolucije
1280 x 960, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Podržani video načini
960p, 720p, 1080p
Materijal kućišta
Metalno
Broj antena
1
Podržani video formati
H.265, H.264B, H.264
Maksimalna veličina memorijske kartice (GB)
256
Svjetlosni tok (lm)
0.0025
Vrsta napajanja
DC
Široki dinamički raspon (WDR)
Senzor pokreta
Video prijenos
Kontrola panela kamere
Tehnologija povezivanja
Žičano i bežično
Pohrana
Kapacitet ROM-a (MB)
16
Ugrađeni tvrdi disk
Flash memorija (MB)
64
Kompatibilne memorijske kartice
MicroSD (TransFlash)
Integriran čitač kartica
Maksimalna veličina memorijske kartice (GB)
256
Noćni vid
Vrsta LE dioda
IC
Noćno snimanje
Broj LED dioda za osvjetljenje
3
Ergonomija
Raspon kuta nagiba (°)
0 - 75°
Optički sustav
Mogućnost zumiranja
Fokusna daljina (mm)
2.8 mm
Tip senzora
CMOS
Veličina optičkog senzora (")
25,4 / 2,8 mm (1 / 2.8")
Maksimalna blenda
2
Promjer leće (mm)
2.8
Kut vidnog polja (FOV) (°)
120
Broj leća
1
Fiksni fokus
Udaljenosti promatranja (m)
18.8
Otkrivanja udaljenosti (m)
46.9
Prepoznavanje udaljenosti (m)
9.4
Određivanje udaljenosti (m)
4.7
Kut objektiva, horizontalno (°)
100°
Kut objektiva, vertikalno (°)
53°
Kut objektiva, dijagonalno (°)
120°
Sistemski zahtjevi
Broj korisnika (korisnik(ci))
6
Podržani Mobilni operativni sustavi
iOS, Android
Karakteristike
Težina (g)
414
Dozvoljeni raspon temperatura za skladištenje (T-T) (°C)
