Technical details
Products per pallet (air): 72 pc(s)
Shipping (inner) case height: 48.5 cm
Pallet height (air): 2.08 m
Pallet gross length: 110 cm
Shipping (inner) case length: 53 cm
Shipping (inner) case gross weight: 22.6 kg
Shipping (inner) case net weight: 14.3 kg
Products per shipping (inner) case: 3 pc(s)
Master (outer) cases per pallet (sea): 24 pc(s)
Pallet gross weight (sea): 561.6 kg
Pallet gross width: 120 cm
Pallet gross weight (air): 561.6 kg
Master (outer) cases per pallet (air): 24 pc(s)
Products per pallet (sea): 72 pc(s)
Pallet height (sea): 2.08 m
Shipping (inner) case width: 38.5 cm
Design
Rack mounting: Yes
Number of fans: 2 fan(s)
LED indicators: Power, Link, Speed, Activity, PoE
Stackable: Yes
Safety: cUL, CB
Product colour: Black, Grey
Power
Power consumption (max): 436.3 W
Power supply included: Yes
AC input voltage: 100 240 V
Power source: AC
Security
DHCP features: DHCP client, DHCP server
Authentication: MACbased authentication, Portbased authentication
Security algorithms: EAP, SNMP, SSL/TLS, 802.1x RADIUS, SSH, SSH2
IGMP snooping: Yes
SSH/SSL support: Yes
BPDU filtering/protection: Yes
Access Control List (ACL) rules: 768
Access Control List (ACL): Yes
Operational conditions
Heat dissipation: 1487.78 BTU/h
Operating temperature (TT): 5 50 C
Storage temperature (TT): 20 70 C
Storage relative humidity (HH): 0 95%
Operating relative humidity (HH): 0 95%
Management features
Traffic classification: Yes
Switch layer: L2/L3
Switch type: Managed
Quality of Service (QoS) support: Yes
System event log: Yes
Weight & dimensions
Width: 440 mm
Height: 44 mm
Weight: 4.25 kg
Depth: 308.5 mm
Network
Networking standards: IEEE 802.1D, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.1w
Cable types supported: Cat5, Cat5e
Virtual LAN features: Tagged VLAN, Protocolbased VLAN
Copper ethernet cabling technology: 10BASET, 100BASETX, 1000BASET
Autonegotiation: Yes
10G support: Yes
Port mirroring: Yes
Full duplex: Yes
Spanning tree protocol: Yes
Number of VLANs: 4094
MAC address autolearning supported: Yes
Headofline (HOL) blocking: Yes
Flow control support: Yes
Link aggregation: Yes
Auto MDI/MDIX: Yes
VLAN support: Yes
Broadcast storm control: Yes
Performance
Flash memory: 32 MB
Internal memory: 256 MB
Mean time between failures (MTBF): 274796 h
Processor frequency: 400 MHz
Builtin processor: Yes
Packaging data
Package weight: 7.06 kg
Package depth: 510 mm
Package width: 450 mm
Package height: 121 mm
Ports & interfaces
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 24
SFP+ module slots quantity: 4
Fiber optic connector: SFP+
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames: 9216
Storeandforward: Yes
MAC address table: 16384 entries
Switching capacity: 128 Gbit/s
Packet buffer memory: 1.5 MB
Number of queues: 8
Jumbo frames support: Yes
Throughput: 95.24 Mpps
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 24
Multicast features
Multicast support: Yes
