Opis i karakteristike
Design
Product colour: Grey, Black
LED indicators: Yes
Power
Power source: AC
Power consumption (max): 9.4 W
Power supply included: Yes
AC input frequency: 50/60 Hz
AC input voltage: 100 240 V
Number of power supply units: 1
Security
IGMP snooping: Yes
Loop protection: Yes
Operational conditions
Heat dissipation: 507.23 BTU/h
Operating relative humidity (HH): 0 95%
Operating temperature (TT): 5 50 C
Storage relative humidity (HH): 0 95%
Storage temperature (TT): 40 70 C
Management features
Switch layer: L2
Webbased management: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Depth: 180 mm
Weight: 1.77 kg
Width: 330 mm
Height: 44 mm
Network
VLAN support: Yes
Networking standards: IEEE 802.3x, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3at, IEEE 802.3u
Spanning tree protocol: Yes
Port mirroring: Yes
Flow control support: Yes
Broadcast storm control: Yes
Headofline (HOL) blocking: Yes
Auto MDI/MDIX: Yes
10G support: No
Ethernet LAN data rates: 10,100,1000 Mbit/s
Full duplex: Yes
Link aggregation: Yes
Number of VLANs: 256
Half duplex: Yes
Performance
Flash memory: 32 MB
Internal memory: 128 MB
Mean time between failures (MTBF): 1274005 h
Certificates
Compliance certificates: BSMI, CCC, CB, cUL
Ports & interfaces
Basic switching RJ45 Ethernet ports quantity: 8
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity: 2
Data transmission
Static route: Yes
Jumbo frames: 10000
Packet buffer memory: 4.1 MB
Forwarding rate: 14.88 Mpps
Switching capacity: 20 Gbit/s
MAC address table: 8000 entries
Jumbo frames support: Yes
Number of static routes: 256
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 130 W
Sustainability
Sustainability compliance: Yes
