Opis i karakteristike
Design
Product colour: Black
LED indicators: Yes
Wall mountable: Yes
Housing material: Metal
International Protection (IP) code: IP30
Number of fans: 0 fan(s)
Rack mounting: Yes
Electromagnetic compatibility: CISPR 22, FCC Part 15B Class A
DIN rail mounting: Yes
Power
Power consumption (max): 10.26 W
DC input voltage: 12 48 V
Security
Security algorithms: SSL/TLS, 802.1x RADIUS
IGMP snooping: Yes
DHCP features: DHCP client
Authentication type: RADIUS
Authentication: Portbased authentication
Queue scheduling algorithms: SPQ, Weighted Round Robin (WRR)
Operational conditions
Operating temperature (TT): 40 65 C
Storage relative humidity (HH): 0 95%
Storage temperature (TT): 40 85 C
Operating relative humidity (HH): 0 95%
Heat dissipation: 35.01 BTU/h
Management features
Webbased management: Yes
Quality of Service (QoS) support: Yes
System event log: Yes
Switch layer: L2
Configuring Location Settings (CLI): Yes
Switch type: Managed
Weight & dimensions
Weight: 1.63 kg
Height: 210 mm
Depth: 53 mm
Width: 171.2 mm
Network
Networking standards: IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.3az, IEEE 802.1w
Number of VLANs: 4094
VLAN support: Yes
Full duplex: Yes
Copper ethernet cabling technology: 10BASET, 1000BASET, 100BASETX
Auto MDI/MDIX: Yes
10G support: No
Port mirroring: Yes
Virtual LAN features: Portbased VLAN, Tagged VLAN, Voice VLAN
Link aggregation: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Autonegotiation: Yes
Flow control support: Yes
Active link detection: Yes
Performance
Mean time between failures (MTBF): 276773 h
Protocols
Management protocols: SNMP v1/v2c/v3, SNTP, Telnet
Ports & interfaces
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Basic switching RJ45 Ethernet ports quantity: 10
Console port: RJ45
Gigabit Ethernet (copper) ports quantity: 10
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 24 Gbit/s
MAC address table: 8000 entries
Jumbo frames support: Yes
Forwarding rate: 17.85 Mpps
Storeandforward: Yes
Jumbo frames: 9216
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Optical fiber
Fiber ethernet cabling technology: 1000BASEX
