Be Quiet! Napajanje BE QUIET Straight Power 12 1000W, BN338 cijene

Technical details
Sustainability certificates: UKCA, WEEE, Triman, RoHS, CE, Federal Communications Commission (FCC), ENERGY STAR, ErP
Sustainability compliance: Yes
Warranty period: 10 year(s)

Design
Fan speed: 0 2100 RPM
Cooling type: Active
Fan diameter: 13.5 cm
On/off switch: Yes
Number of fans: 1 fan(s)
Product colour: Black

Power
Max output current (+12V): 83.3 A
Max output current (+3.3V): 25 A
Combined power (+3.3V): 150 W
Combined power (+5V): 150 W
Combined power (+12V): 999.6 W
Max output current (12V): 0.5 A
Hold time: 25.3 ms
Max output current (+5V): 25 A
Max output current (+5Vsb): 3 A
Peak power: 1070 W
Power factor: 0.99
Efficiency: 91.8%
AC input voltage: 100 240 V
Input current: 13/6.5 A
Power protection features: Over voltage, Over power, Overheating, Under voltage, Over current
AC input frequency: 50/60 Hz
Total power: 1000 W

Operational conditions
Operating temperature (TT): 0 40 C

Weight & dimensions
Height: 86 mm
Width: 150 mm
Depth: 160 mm
Weight: 1.85 kg

Performance
ATX version: 3.0
Bearing technology: FDB
EPS version: 2.92
Purpose: PC
Noise level: 28.9 dB
80 PLUS certification: 80 PLUS Platinum
Mean time between failures (MTBF): 100000 h
Supported motherboard form factors: ATX, micro ATX, MiniATX
Power supply unit (PSU) form factor: ATX

Packaging data
Package type: Box
Package height: 102 mm
Package weight: 3.56 kg
Package width: 248 mm
Package depth: 328 mm

Packaging content
Cable tie(s) included: Yes
Cables included: CPU, SATA

Ports & interfaces
PCI Express power connectors (16pin): 1
PCI Express power cable length: 60 cm
SATA power cable length: 700, 1000 mm, 550, 850 mm
EPS power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 9
Peripheral (Molex) power cable length: 850 mm, 1000
Motherboard power cable length: 60 cm
CPU power cable length: 70 cm
Number of PATA power connectors: 2
PCI Express power connectors (6+2 pin): 4
EPS power connector (8pin): Yes
Cabling type: FullyModular

Logistics data
Shipping (inner) case net weight: 22.9 kg
Products per shipping (inner) case: 6 pc(s)
Shipping (inner) case length: 65.1 cm
Shipping (inner) case height: 34.6 cm
Shipping (inner) case width: 28.2 cm
