AsRock B860 LiveMixer WiFi LGA1851 MB cijene

Processor
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)

Graphics
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 7680 x 4320 pixels
Certification: FCC, CE, ErP/EuP

Features
Windows operating systems supported: Windows 11 x64
Motherboard chipset: Intel B860
Product colour: Black
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Audio chip: Realtek ALC1220
Motherboard form factor: ATX

Memory
ECC ompatibility: NonECC
Number of memory slots: 4
Memory channels: Dualchannel
Supported memory types: DDR5SDRAM
Memory slots type: DIMM
Maximum internal memory: 256 GB
Unbuffered memory: Yes

Weight & dimensions
Width: 305 mm
Depth: 244 mm

Network
WiFi standards: WiFi 5 (802.11ac), 802.11g, WiFi 6E (802.11ax), WiFi 4 (802.11n), 802.11a, WiFi 6 (802.11ax), 802.11b
Top WiFi standard: WiFi 6E (802.11ax)
WiFi: Yes
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
LAN controller: Dragon RTL8125BG
Bluetooth: Yes

Internal I/O
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
Number of EPS power connectors (8pin): 2
RGB LED pin header: Yes
Number of chassis fan connectors: 5
TPM connector: Yes
EPS power connector (8pin): Yes
CPU fan connector: Yes
Number of water pump connectors: 1
12V power connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
ATX Power connector (24pin): Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
USB 2.0 connectors: 2

BIOS
BIOS type: UEFI AMI

Packaging content
Antenna included: Yes
Cables included: SATA

Storage controllers
RAID levels: 1, 5, 10, 0
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID support: Yes

Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 6
HDMI version: 2.1
Microphone in: Yes
Headphone outputs: 1
HDMI ports quantity: 1
Thunderbolt ports quantity: 1
WiFiAP antenna jack: 2
USB connector type: USB TypeA, USB TypeC
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 6
S/PDIF out port: Yes

Expansion slots
1st M.2 largest key size: 2280
Number of M.2 (M) slots: 3
2nd M.2 largest key size: 2280
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 highest PCI Express generation: 4.0

Safety warning
Warnings: In case of installation problems, contact a qualified service technician., Do not open or modify the motherboard to prevent damage., When disposing of the product, follow local regulations for the recycling of electronics.
