Opis i karakteristike
Processor
Maximum number of SMP processors: 1
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 3, AMD Ryzen 5
Processor socket: Socket AM5
Graphics
Onboard graphics card model: Aspeed AST2600
Features
PC health monitoring: Voltage, Fan, CPU
Motherboard chipset: AMD B650 Express
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Component for: Server
Memory
Supported memory clock speeds: 5200, 3600
Maximum internal memory: 32 GB
Memory voltage: 1.1 V
Supported memory types: DDR5SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Supported memory clock speed (max): 5200 MHz
ECC ompatibility: ECC & NonECC
Operational conditions
Operating temperature (TT): 10 35 C
Operating relative humidity (HH): 20 90%
Storage temperature (TT): 40 70 C
Weight & dimensions
Width: 243.8 mm
Depth: 243.8 mm
Network
Ethernet LAN: Yes
WiFi: No
Internal I/O
Number of SATA III connectors: 4
ATX Power connector (24pin): Yes
EPS power connector (8pin): Yes
TPM connector: Yes
Number of COM connectors: 1
BIOS
BIOS memory size: 256 Mbit
ACPI version: 6.4
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
System Management BIOS (SMBIOS) version: 3.5
Storage controllers
RAID levels: 1, 0, 10
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ45) ports: 4
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 4
VGA (DSub) ports quantity: 1
IPMI LAN (RJ45) port: Yes
Serial ports quantity: 1
Expansion slots
PCI Express x4 (Gen 4.x) slots: 1
