Opis i karakteristike
Design
LED indicators: Yes
Form factor: 1U
Product colour: Black
Rack mounting: Yes
Number of fans: 2 fan(s)
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 240 V
Power consumption (max): 299.4 W
Power source: AC
Power supply included: Yes
Security
Security algorithms: SSH, SSH2, HTTPS, SSL/TLS
MAC address filtering: Yes
DHCP features: DHCP server, DHCP snooping, DHCPv6 snooping, DHCPv6 client, DHCP client, DHCP relay
SSH/SSL support: Yes
IGMP snooping: Yes
Loop protection: Yes
Static port security: Yes
Access Control List (ACL): Yes
BPDU filtering/protection: Yes
Queue scheduling algorithms: SP, WRR+SP, Weighted Round Robin (WRR)
Authentication type: AAA, TACACS+
Password protection: Yes
IPMACPort binding: Yes
Authentication: MACbased authentication, Portbased authentication
Operational conditions
Operating relative humidity (HH): 10 90%
Storage temperature (TT): 40 70 C
Operating temperature (TT): 0 50 C
Storage relative humidity (HH): 5 90%
Heat dissipation: 1021.64 BTU/h
Management features
Quality of Service (QoS) support: Yes
Webbased management: Yes
Switch layer: L2+
Cloudmanaged: Yes
Switch type: Managed
System event log: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
Weight & dimensions
Width: 440 mm
Height: 44 mm
Depth: 180 mm
Network
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Networking standards: IEEE 802.1w, IEEE 802.1s, IEEE 802.1D
10G support: Yes
Spanning tree protocol: Yes
Port mirroring: Yes
VLAN support: Yes
Virtual LAN features: Portbased VLAN, Voice VLAN, Tagged VLAN, MAC addressbased VLAN, Protocolbased VLAN, Private VLAN
Broadcast storm control: Yes
Flow control support: Yes
Rate limiting: Yes
Link aggregation: Yes
IP routing: Yes
Headofline (HOL) blocking: Yes
Packaging data
Package type: Box
Packaging content
Quick start guide: Yes
Cables included: AC
Certification: CE, FCC, RoHS
Certificates
Compliance certificates: RoHS, Federal Communications Commission (FCC)
Protocols
Management protocols: SNMP v1/v2c/v3, SNTP
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Console port: RJ45/microUSB
Basic switching RJ45 Ethernet ports quantity: 16
SFP+ module slots quantity: 2
Power connector: ACin jack
Basic switching RJ45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Data transmission
MAC address table: 16000 entries
Static route: Yes
Number of IP interfaces: 32
Jumbo frames: 9000
Forwarding rate: 89.28 Mpps
Number of static routes: 48
Switching capacity: 120 Gbit/s
Packet buffer memory: 12 MB
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE) power per port: 30 W
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
Sustainability
Sustainability compliance: Yes
